Performance
Battery, Range, and Charging
The battery has a gross capacity of 30.5 kWh and a net usable capacity of 28.0 kWh, with a 2.5 kWh buffer (8.2%) for battery protection. With a nominal voltage of 360 volts, the system is classified as a 400-volt battery system.
The lithium-ion battery uses NMC (nickel manganese cobalt) chemistry.
For more details about the range, see real-world data and range listings on this model’s range and consumption page.
The vehicle supports fast DC charging with a maximum power of 69 kW. A 0–100% charge takes approximately 92 minutes. A typical 10–80% session takes about 25 minutes at an average power of 47 kW.
With five minutes of overhead per stop, the optimal charging window is 0–60%. Effective average power, including overhead, is 47 kW over a session lasting about 21 minutes and 24 seconds.
Onboard Charger
The standard onboard charger supports AC charging at up to 6.6 kW. A full 0–100% charge takes about 4 hours and 14 minutes with a suitable home charging setup.
Charge Port
The charge port is on the left rear side. This position suits charging bays where the vehicle reverses toward the charging point.
Drivetrain
The Hyundai IONIQ Electric 28 kWh has a front-wheel drive system supported by one motor on the front axle.
The motor used is Permanent Magnet Synchronous Motor.
Suspension
en drivetrain.suspension.standard.frontconstruction_macphersonstrut.rearconstruction_torsionbeam.frontdampers_notset.reardampers_notset.frontspring_coil.rearspring_coil
The Standard suspension has a fixed height and damping characteristics.
Ground clearance with this setup is 140 mm.
Drive Modes
The Hyundai IONIQ Electric 28 kWh lets the user select different drive modes that affect the car's handling.
The driver can choose between 3 modes:
- Eco: Comfort steering and efficient throttle.
- Normal: Balanced steering and throttle.
- Sport: Dynamic steering and throttle.
Brakes
The Hyundai IONIQ Electric 28 kWh is equipped with cast-iron disc brakes on both the front and rear.
The front discs measure 280 mm, while the rear discs are 284 mm.
Regenerative Braking
Regenerative braking works in two ways: through one-pedal driving, or through the brake pedal using blended braking while coasting.
Drivers can also adjust the regenerative braking strength when lifting off the accelerator. There are four levels of regenerative braking to choose from, allowing you to customize the driving experience to your preference.
The maximum regenerative braking power is 50 kW.
Exterior
The Hyundai IONIQ Electric 28 kWh, with dimensions of 4470 mm in length, 1820 mm in width, and 1450 mm in height, falls into the C-segment, also known as compact cars.
The Hyundai IONIQ Electric 28 kWh is available in 5 paint colors, including both solid and metallic options.
You can select from multiple wheel designs, all available in the same size, on the Hyundai IONIQ Electric 28 kWh. The available tire and wheel combinations include:
- 205/55 tires on 16" rims
The car has four regular doors and a hatchback-style liftgate.
There is only one roof option for this model.
A conventional roof is standard.
Hyundai IONIQ Electric 28 kWh
Interior
Seats
The Hyundai IONIQ Electric 28 kWh accommodates five passengers with two front seats and a three-seat bench in the rear.
First Row Seats
The Hyundai IONIQ Electric 28 kWh offers a single type of front seat.
The following functionalities are available on the seat:
- Fore-and-aft adjustment (manually adjustable)
- Recline adjustment (manually adjustable)
- Height adjustable headrest
- Heating
Available in:
- Black/Gray fabric upholstery
Second-Row Seats
The second row features a standard three-seat bench with a 60:40 split, allowing each section to fold separately to increase cargo space.
Additional second-row features include:
- Height adjustable headrest (standard for outer seats)
- ISOFIX (standard for outer seats)
Interior Storage
The Hyundai IONIQ Electric 28 kWh has the following interior storage:
- Glove Compartment: Located in the dashboard in front of the passenger.
- Center Console: A storage compartment is located beneath the front center armrest.
- Door Pockets: The front and rear doors include integrated storage pockets.
Interior Lighting
The Hyundai IONIQ Electric 28 kWh offers several interior lighting options.
- Ambient Lighting: Extends across the dashboard.
Climate System
There is one climate system available:
- 1-zone climate system: Controls a single zone for the whole cabin.
A heat pump is available as an option and can reduce the energy needed to heat the cabin in cold weather.
User Interface and Control
The Hyundai IONIQ Electric 28 kWh features a screen-focused control interface with limited physical buttons and no stalks, providing a minimalist approach to vehicle controls. This design prioritizes touchscreen interaction, which may appeal to tech-savvy users but could be less intuitive for those accustomed to traditional controls.
Key screen details:
- en uicontrols.screen.info.InCenterOfDash.touch
The Hyundai IONIQ Electric 28 kWh does not have a head-up display. Speed and navigation information remain on the vehicle's other displays.
Hyundai IONIQ Electric 28 kWh
Steering Wheel
The Hyundai IONIQ Electric 28 kWh is equipped with a single type of steering wheel:
The steering wheel adjusts for tilt and reach. The adjustment is manual.
Design: Circular flat-bottom
Controls: Physical buttons, Scroll wheels
Heating: Heated (standard)
From the steering wheel you can control:
- Audio control
- Phone Controls: Buttons on the steering wheel allow you to answer, end, and manage phone calls.
- Cruise Control: A stalk or button on the steering wheel allows you to set and adjust the cruise control speed.
- Voice Control: A button on the steering wheel activates the voice control system.
- Drive Mode Selector: A dedicated control allows you to switch between different drive modes.
Mirrors
Both the exterior and interior mirrors use conventional mirror technology to provide a clear view of the area behind the vehicle.
Voice control is standard.
Infotainment
The Hyundai IONIQ Electric 28 kWh features a proprietary infotainment system with basic navigation and vehicle information.
Navigation System
With the optional in-car navigation system, you have all the assistance you need to reach your destination effortlessly.
Phone Mirroring
The Hyundai IONIQ Electric 28 kWh supports Android Auto and Apple CarPlay, providing access to compatible phone apps such as Google Maps and Waze on the car's display.
Sound System
The Hyundai IONIQ Electric 28 kWh has one sound system option:
- Standard Audio: Features six speakers.
The model includes USB-A connectivity as standard (total: 1).
Mobile App
The Hyundai IONIQ Electric 28 kWh has a mobile app for Android and iOS to manage and monitor the vehicle remotely. Features:
- Locate Your Vehicle: Check the current location of your car.
- Preconditioning: Preheat or cool your car before you start your journey.
- Lock and unlock: Lock or unlock the doors remotely.
- Charge Target: Set the battery's target state of charge.
- Find your car: Sound the horn or flash the lights to locate the car.
Lights
Standard Headlights: These use LED technology and include corner lights that illuminate the side when turning.
The taillights use LED technology.
Advanced Driver Assistance Systems
The Hyundai IONIQ Electric 28 kWh offers standard and optional advanced driver assistance systems (ADAS).
Safety Systems
Anti-lock Braking System (ABS): Standard on the Hyundai IONIQ Electric 28 kWh. It prevents the wheels from locking during braking.
Electronic Stability Control (ESC): Standard on the Hyundai IONIQ Electric 28 kWh. It improves stability during sudden maneuvers and on slippery roads.
Lane-Keeping Assist (LKA): Standard on the Hyundai IONIQ Electric 28 kWh. It applies steering corrections if the vehicle begins to leave its lane.
The Lane Departure Warning alerts the driver if the vehicle begins to leave its lane.
Rear Cross Traffic Alert (RCTA): Standard on the Hyundai IONIQ Electric 28 kWh. It detects vehicles approaching from the side while reversing out of a parking space or driveway.
Forward Collision Warning (FCW): Standard on the Hyundai IONIQ Electric 28 kWh. It warns the driver of a potential frontal collision.
Automatic Emergency Braking (AEB): Standard on the Hyundai IONIQ Electric 28 kWh. It applies the brakes automatically if the driver does not respond to an imminent collision.
Blind-spot Monitoring (BSM): Standard on the Hyundai IONIQ Electric 28 kWh. It detects traffic in the vehicle's blind spots.
Driving Automation
With the standard system the model offers no driving automation.
- Cruise control.
Safety
The Hyundai IONIQ Electric 28 kWh is equipped with the following airbags:
- Front airbags for the driver and front passenger
- Side curtain airbags for both the first and second rows
- Side airbags for the driver and front passenger
The front and rear seatbelts are equipped with pyrotechnic pretensioners and load limiters. In the event of a collision, the pretensioners tighten the seatbelts to secure occupants firmly in their seats, while the load limiters allow a controlled amount of webbing to extend, reducing the risk of injury from excessive force.
Security and Access Technologies
The Hyundai IONIQ Electric 28 kWh includes the following security and access features:
- Keyless Entry and Start: Unlock and start the car with the key in your pocket or bag.
- Alarm System: Monitors for unauthorized entry or tampering and sounds the alarm when triggered.
Cargo Capacity and Towing Ability
The trunk offers a cargo capacity of 350 liters (12.4 cu ft). With the rear seat folded down, this expands to 1410 liters (49.8 cu ft).
The maximum permitted vehicle weight is 1880 kg (4145 lbs), and the base curb weight is 1475 kg (3252 lbs). This leaves a payload of 405 kg (893 lbs), including occupants. Options can increase curb weight and reduce payload.
This model is not available with a towbar and cannot tow a trailer.
