Zeekr 001 FR

Zeekr 001 FR is an all-electric station wagon with a WLTP range of up to 580 km (361 miles). EVKX.net has all the details.

Zeekr 001 FR

Zeekr 001 FR

We’ve organized this article into specific sections for easier navigation. Click the links below to jump to different areas or read on for the full article. Additionally, we offer an overview of the full specifications, an image gallery, detailed information about charging performance, and some online reviews. Our sections include:

Performance

The Zeekr 001 FR delivers a jaw-dropping maximum power of 930 KW (1264 hp/1247 bhp) and a massive total torque of 1200 Nm (886 lb-ft). This powerhouse can rocket from 0 to 100 km/h (0 to 62 mph) in just 2.02 seconds, showcasing its astonishing acceleration. Additionally, it achieves a top speed of 280 km/h (174 mph), making it a true marvel of engineering and performance.

Battery, Range, and Charging

The high-capacity battery has a gross capacity of 100.0 kWh and a net usable capacity of 95.0 kWh, providing a 5.0 kWh buffer (5.0%) for battery protection. With a nominal voltage of 370 volts, the system is classified as a 400-volt battery system, aligning with industry standards. This Lithium-Ion battery utilizes NMC (Nickel Manganese Cobalt) technology.

According to the WLTP (Worldwide Harmonized Light Vehicles Test Procedure) standard, the vehicle’s range is 580 km (361 miles), with an energy consumption rate of 16.4 kWh/100 km (3 mi/kWh). For more details about the range, see real-world data and range listings on this model’s range and consumption page.

The vehicle supports fast DC charging with a maximum power of 200 kW. Charging from 0% to 100% takes approximately 59 minutes, while a more typical scenario from 10% to 80% takes 28 minutes with an average charging speed of 144 kW. Considering an additional 5 minutes for each charging stop due to driving interruptions, the optimal charging range is from 4% to 57%. This results in an effective charging speed, including time lost, of 132 kW, with each charging session taking about 23 minutes and 51 seconds.

In a theoretical 1000 km challenge, starting with a full battery and maintaining a constant speed of 120 km/h (75 mph) under ideal conditions with an assumed consumption rate of 28 kWh/100 km, the trip would take approximately 9 hours and 44 minutes. This journey would require four charging stops from 5% to 54%, with a total charging time of 85 minutes.

Onboard Charger

The standard onboard charger supports up to 11 kW for Level 1 and Level 2 AC charging. This allows you to fully charge the battery from 0 to 100% in approximately 8 hours and 38 minutes using a home charging setup.

Charge Port

The charge port is located on the left rear side, making it easy to use charge stations where you need to back up into the charger. Connector types vary by market: this model uses CCS Combo 1 in North America and CCS Combo 2 in Europe. For complete specifications for all markets, refer to the full specifications.

Drivetrain

The Zeekr 001 FR has an all-wheel drive system supported by four motors. One for each wheel. The motors used are Permanent Magnet Synchronous Motors.

Suspension

The front suspension is double wishbone, and the rear suspension is Multilink. It uses air suspension and hydraulic dampers. The suspension is fully adaptive on the front and rear axle, so height and damping can be adjusted manually and automatically. The minimum ground clearance is 162 mm, and the maximum is 192 mm.

Brakes

The rear and front brakes are ceramic discs. The front discs measure 533 mm, while the rear discs are 457 mm.

Regenerative Braking

Automatic regeneration is not available in this model. However, regenerative braking is facilitated through one-pedal driving combined with blended brakes.

Exterior

The Zeekr 001 FR, with dimensions of 4955 mm in length, 1999 mm in width, and 1548 mm in height, falls into E-segment cars, also known as executive cars, are larger and more luxurious than their D-segment counterparts. They are designed to offer superior comfort, advanced technology, and high performance, making them suitable for a specific set of drivers. The Zeekr 001 FR is available in a total of 4 paint colors, including several striking metallic options.

You can select from multiple wheel designs, all available in the same size, on the Zeekr 001 FR, allowing you to personalize your vehicle to match your style and driving preferences. The available tire and wheel combinations include:

  • 265/40 tires on 22" rims

The car has four regular doors and a hatchback-style liftgate.

There is only one roof option for this model. The standard roof has a large panoramic roof extending over most areas from the front to the rear. This glass makes the car’s interior feel more spacious and bright, which can improve the mood and comfort of the occupant. The glass is toned to protect against heat from the sun.

The windows from the B-pillar and back are tinted, which enhances privacy and reduces glare and heat from the sun, making the interior more comfortable for passengers.

Zeekr 001 FR

Zeekr 001 FR

Interior

There is one seat type you can select in different materials.

Seats

The Zeekr 001 FR accommodates five passengers with two front seats and a three-seat bench in the rear.

First Row Seats

The Zeekr 001 FR offers a single type of front seat.

The following functionalities are available on the standard seat:

Available in:

Zeekr 001 FR

Zeekr 001 FR

Second Row Seat

The second row features a standard three-seat bench with a 40:60 split, allowing each section to fold separately to increase cargo space. Additional functionalities include:

Climate System

There is one climate system available:

  • 3-zone climate system: Supports different temperatures in three zones for the driver, passenger, and backseat.

A standard heat pump is included, which can save significant energy that the EV would otherwise use for heating in cold weather.

Comfort Features

The Zeekr 001 FR includes several features to enhance comfort and convenience:

  • Electrically Adjustable Steering Wheel
  • Wireless Phone Charging

User Interface and Control

The Zeekr 001 FR has multiple integrated screens. Behind the steering wheel is a digital instrument cluster, and in the center console, there is one infotainment screen at the top of the center console.

Key screen details:

  • The screen behind the steering wheel integrated into the dashboard is 8.8 inches large
  • The touch screen at the top of the center console is 15.4 inches large

A head-up display is a standard system that projects speed and other important driver information onto the windshield.

Zeekr 001 FR

Zeekr 001 FR

Steering Wheel

The Zeekr 001 FR is equipped with a single type of steering wheel:

  • Circular Steering Wheel: This steering wheel features integrated heating for added comfort during cold weather. It also provides intuitive control over the infotainment system, allowing you to easily adjust the volume, change music tracks, and manage other key functions.

Mirrors

Both the exterior and interior mirrors use conventional mirror technology to provide a clear view of the area behind the vehicle.

This model comes equipped with voice control as standard, allowing you to manage various functions through voice commands.

Infotainment

With the a standard in-car navigation system, you have all the assistance you need to reach your destination effortlessly.

Phone Mirroring

The Zeekr 001 FR supports Android Auto and Apple CarPlay, allowing you to mirror your phone’s screen on the car’s display. This functionality enables you to run apps like Google Maps or Waze directly from your phone.

Sound System

The Zeekr 001 FR comes equipped with one sound system option:

  • Yamaha Sound System: Features 12 speakers and delivers a maximum output of 300 watts.

Additionally, the model includes 3 USB-C connections as standard. The model has 1 USB-A connections as standard.

Lights

The Zeekr 001 FR comes equipped with advanced LED Matrix headlights. This adaptive system divides the traditional single headlight beam into multiple smaller rays, allowing the light controller to selectively turn them on and off to avoid dazzling other drivers. For enhanced safety, the headlights also include corner lights that illuminate the side when turning.

The taillights use LED technology, ensuring both high visibility and energy efficiency.

Advanced Driver Assistance Systems

The Zeekr 001 FR features a range of standard and optional advanced driver assistance systems (ADAS) designed to enhance safety and comfort.

Efficiency Assist: A Standard feature that helps drivers anticipate driving conditions and conserve energy.

Safety Systems

Electronic Stability Control (ESC): Standard on the Zeekr 001 FR, this system improves the vehicle’s stability and handling during sudden maneuvers or on slippery road conditions.

Lane-Keeping Assist (LKA): Standard on the Zeekr 001 FR, this system helps prevent the vehicle from drifting out of its lane. It also includes a Lane Departure Warning system to alert the driver if the vehicle veers out of the lane.

Rear Cross Traffic Alert (RCTA): Standard on the Zeekr 001 FR, this system uses sensors to detect approaching vehicles from the side when backing out of a parking space or driveway.

Forward Collision Warning (FCW): Standard on the Zeekr 001 FR, this driver assist system helps drivers avoid or mitigate frontal collisions.

Automatic Emergency Braking (AEB): Standard on the Zeekr 001 FR, this system autonomously applies the brakes to prevent or reduce the severity of a collision if the driver does not react in time.

Driving Automation

With the standard Pilot Assist level 2 system, you get the following driving automation features.

Security and Access Technologies

The Zeekr 001 FR is equipped with advanced security features to protect you and your vehicle. These include:

  • Keyless Entry and Start: The vehicle’s keyless entry and start system enables seamless access, allowing you to unlock and start the car without needing to remove the key from your pocket or bag.

Cargo Capacity and Towing Ability

The trunk offers a cargo capacity of 539 liters (19.0 CU FT). With the rear seat folded down, this expands to 1411 liters (49.8 CU FT). On the roof, you can load up to 100 kg (220.5 lbs). Additionally, there is a frunk (front trunk) with a storage capacity of 32 liters (1.1 CU FT).

The vehicle’s maximum weight is 3080 kg (6790 lbs), with a base weight of 2350 kg (5181 lbs). This allows for a maximum load of 730 kg (1609 lbs), including the driver and passengers. Note that some options may increase the base weight and reduce the maximum loading capacity.

A towbar can be added to the vehicle. The maximum permissible weight for a braked trailer is 2000 kg (4409 lbs), while for an unbraked trailer, it is 750 kg (1653 lbs).

Availability & Pricing

The Zeekr 001 FR had its world premiere on 30.10.2023, with deliveries starting in January 2024.
