XPENG G9 AWD Performance

XPENG G9 AWD Performance is an all-electric SUV with a WLTP range of up to 520 km (323 miles). EVKX.net has all the details.

We’ve organized this article into specific sections for easier navigation. Click the links below to jump to different areas or read on for the full article. Additionally, we offer an overview of the full specifications, an image gallery, detailed information about charging performance, and some online reviews. Our sections include:

• Performance
• Battery, Range, and Charging
• Drivetrain (suspension, brakes, steering)
• Exterior (paint colors, wheels ++)
• Interior (seats++)
• User interface and control
• Infotainment
• Lights
• Advanced driver-assistance systems
• Cargo Capacity and Towing Ability

Performance

The XPENG G9 AWD Performance packs an impressive punch with a maximum power of 405 kW (551 hp / 543 bhp) and a commanding total torque of 717 Nm (529 lb-ft). This high-performance machine can sprint from 0 to 100 km/h (0 to 62 mph) in just 3.9 seconds, and it reaches a top speed of 205 km/h (127 mph), making it a standout in its class.

Battery, Range, and Charging

The high-capacity battery has a gross capacity of 98.0 kWh and a net usable capacity of 93.6 kWh, providing a 4.4 kWh buffer (4.5%) for battery protection. This Lithium-Ion battery utilizes NMC (Nickel Manganese Cobalt) technology.

According to the WLTP (Worldwide Harmonized Light Vehicles Test Procedure) standard, the vehicle’s range is 520 km (323 miles), with an energy consumption rate of 18.0 kWh/100 km (3 mi/kWh). For more details about the range, see real-world data and range listings on this model’s range and consumption page.

The vehicle supports fast DC charging with a maximum power of 300 kW. Charging from 0% to 100% takes approximately 51 minutes, while a more typical scenario from 10% to 80% takes 19 minutes with an average charging speed of 202 kW. Considering an additional 5 minutes for each charging stop due to driving interruptions, the optimal charging range is from 7% to 60%. This results in an effective charging speed, including time lost, of 166 kW, with each charging session taking about 18 minutes and 53 seconds. This exceptionally fast charging capability makes the XPENG G9 AWD Performance one of the most efficient and convenient EVs for long-distance travel.

In a theoretical 1000 km challenge, starting with a full battery and maintaining a constant speed of 120 km/h (75 mph) under ideal conditions with an assumed consumption rate of 26 kWh/100 km, the trip would take approximately 9 hours and 20 minutes. This journey would require three charging stops from 7% to 67%, with a total charging time of 61 minutes.

Onboard Charger

The standard onboard charger supports up to 11 kW for Level 1 and Level 2 AC charging. This allows you to fully charge the battery from 0 to 100% in approximately 8 hours and 30 minutes using a home charging setup.

Charge Port

The location of the charge port is on the right rear side. This location makes it easy to use charge stations where you need to back up into the charger. Connector types vary by market: this model uses CCS Combo 1 in North America and CCS Combo 2 in Europe. For complete specifications for all markets, refer to the full specifications.

Drivetrain

The XPENG G9 AWD Performance features an all-wheel drive system powered by two motors, one on each axle. The motors used are Permanent Magnet Synchronous Motors.

Suspension

The front suspension is double wishbone, and the rear suspension is Multilink. It uses air suspension and hydraulic dampers. The suspension is fully adaptive on the front and rear axle, so height and damping can be adjusted manually and automatically. The minimum ground clearance is 95 mm, and the maximum is 195 mm.

Brakes

The XPENG G9 AWD Performance is equipped with cast-iron disc brakes on both the front and rear.

Regenerative Braking

Regenerative braking is available in two modes. You can use one-pedal driving or you can coast and use the blended brakes to regen. At low speeds, the one-pedal drive mode will keep the car creeping forward.

Exterior

The XPENG G9 AWD Performance, with dimensions of 4891 mm in length, 1937 mm in width, and 1670 mm in height, falls into the Mid-size SUVs offer a blend of space, comfort, performance, and versatility, making them suitable for a wide range of drivers with diverse needs. You can choose between 5 different paint colors when ordering this model.

The XPENG G9 AWD Performance offers multiple wheel options in different sizes, allowing you to customize your vehicle to suit your style and driving preferences. The available tire and wheel combinations include:

The car has four regular doors and a hatchback-style liftgate.

There is only one roof option for this model. The standard roof has a large panoramic roof extending over most of the areas from the front to the rear. This glass makes the car’s interior feel more spacious and bright, which can improve the mood and comfort of the occupant. It has an electric curtain that occupants can use to protect against the sun.

The windows from the B-pillar and back are tinted, which enhances privacy and reduces glare and heat from the sun, making the interior more comfortable for passengers.

Interior

Seats

The XPENG G9 AWD Performance accommodates five passengers with two front seats and a three-seat bench in the rear.

First Row Seats

The XPENG G9 AWD Performance offers a single type of front seat.

The following functionalities are available on the **** seat:

• Fore-and-aft adjustment (electrically adjustable)
• Recline adjustment (electrically adjustable)
• Height adjustment (electrically adjustable)
• Seat cushion angle adjustment (electrically adjustable)
• Heating
• Memory (standard for driver, not available for passenger)
• Adjustable lumbar support (electrically adjustable)
• Backrest side bolsters adjustment
• Seat cushion side bolsters adjustment
• Adjustable thigh support
• Ventilation
• Massage

Available in:

• Black Nappa leather upholstering
• Beige Nappa leather upholstering

Second Row Seat

The second row features a standard three-seat bench with a 60:40 split, allowing each section to fold separately to increase cargo space. Additional functionalities include:

• Heating (standard for outer seats)
• Massage

Climate System

There is one climate system available:

• 4-zone climate system: Supports different temperatures for the driver, passenger, and two separate passengers in the back seat

A standard heat pump is included, which can save significant energy that the EV would otherwise use for heating in cold weather.

Comfort Features

The XPENG G9 AWD Performance includes several features to enhance comfort and convenience:

• Electrically Adjustable Steering Wheel
• Wireless Phone Charging

User Interface and Control

The XPENG G9 AWD Performance has twin screens with information for the driver and passengers. Behind the steering wheel is a digital instrument cluster. In addition, there is one infotainment screen in the center console and one infotainment screen in front of the passenger seat.

Key screen details:

• The screen behind the steering wheel mounted into the dashboard is 10.3 inches large
• The touch screen on the dashboard’s center is 15.0 inches large
• The touch screen in front of the passenger on the dashboard is 15.0 inches large

The model does not include a head-up display.

Steering Wheel

The XPENG G9 AWD Performance is equipped with a single type of steering wheel:

• Circular Steering Wheel: This steering wheel features integrated heating for added comfort during cold weather. It also provides intuitive control over the infotainment system, allowing you to easily adjust the volume, change music tracks, and manage other key functions.

Mirrors

Both the exterior and interior mirrors use conventional mirror technology to provide a clear view of the area behind the vehicle.

This model comes equipped with voice control as standard, allowing you to manage various functions through voice commands.

Infotainment

Navigation System

With the a standard in-car navigation system, you have all the assistance you need to reach your destination effortlessly.

Sound System

The XPENG G9 AWD Performance comes equipped with one sound system option:

• : Features 24 speakers and delivers a maximum output of 1940 watts.

Lights

Standard Headlights: These use advanced LED technology, providing bright and efficient illumination.

The taillights use LED technology, ensuring both high visibility and energy efficiency.

Advanced Driver Assistance Systems

The XPENG G9 AWD Performance features a range of standard and optional advanced driver assistance systems (ADAS) designed to enhance safety and comfort.

Safety Systems

Anti-lock Braking System (ABS): Standard on the XPENG G9 AWD Performance, this system prevents the wheels from locking during braking.

Electronic Stability Control (ESC): Standard on the XPENG G9 AWD Performance, this system improves the vehicle’s stability and handling during sudden maneuvers or on slippery road conditions.

Lane-Keeping Assist (LKA): Standard on the XPENG G9 AWD Performance, this system helps prevent the vehicle from drifting out of its lane. It also includes a Lane Departure Warning system to alert the driver if the vehicle veers out of the lane.

Front Cross Traffic Assist (FCTA) : Standard on the XPENG G9 AWD Performance, this driver assist system that helps drivers detect oncoming traffic when crossing an intersection or turning left or right from a stopped position.

Rear Cross Traffic Alert (RCTA): Standard on the XPENG G9 AWD Performance, this system uses sensors to detect approaching vehicles from the side when backing out of a parking space or driveway.

Forward Collision Warning (FCW): Standard on the XPENG G9 AWD Performance, this driver assist system helps drivers avoid or mitigate frontal collisions.

Automatic Emergency Braking (AEB): Standard on the XPENG G9 AWD Performance, this system autonomously applies the brakes to prevent or reduce the severity of a collision if the driver does not react in time.

Blind-spot Monitoring (BSM) : Standard on the XPENG G9 AWD Performance, this side assist system helps to detect traffic in blind spots.

Driving Automation

With the standard level 2 system, you get the following driving automation features.

• Adaptive Cruise Control (ACC)
• Lane Centering Assist (LCA) /AutoSteer: keeps the car in your lane and slows down if needed in traffic. The system limits how long you can drive without touching the steering wheel.
• Automatic parking.

Security and Access Technologies

The XPENG G9 AWD Performance is equipped with advanced security features to protect you and your vehicle. These include:

• Keyless Entry and Start: The vehicle’s keyless entry and start system enables seamless access, allowing you to unlock and start the car without needing to remove the key from your pocket or bag.
• Alarm System: An integrated alarm system monitors for unauthorized entry or tampering, providing alerts to help deter intrusions and keep your vehicle secure.

Cargo Capacity and Towing Ability

The trunk offers a cargo capacity of 660 liters (23.3 CU FT). With the rear seat folded down, this expands to 1576 liters (55.7 CU FT). On the roof, you can load up to 75 kg (165.3 lbs). Additionally, there is a frunk (front trunk) with a storage capacity of 71 liters (2.5 CU FT).

The vehicle’s maximum weight is 2800 kg (6173 lbs), with a base weight of 2360 kg (5203 lbs). This allows for a maximum load of 440 kg (970 lbs), including the driver and passengers. Note that some options may increase the base weight and reduce the maximum loading capacity. 440kg is considered low for this type of car and might restrict how much stuff you can bring in addition to passengers.

A towbar can be added to the vehicle. The maximum permissible weight for a braked trailer is 1500 kg (3307 lbs), while for an unbraked trailer, it is 750 kg (1653 lbs).
