Volkswagen ID.3 Pro S

The Volkswagen ID.3 Pro S is an all-electric hatchback offering a WLTP range of up to 553 km (344 miles). EVKX.net has all the details you need.

We've organized this article into specific sections for easier navigation. Click the links below to jump to different areas or read on for the full article. Additionally, we offer an overview of the full specifications, an image gallery, detailed information about charging performance, and some online reviews. Our sections include:

• Performance
• Battery, Range, and Charging
• Drivetrain (suspension, brakes, and steering)
• Exterior (paint colors, wheels, and more)
• Interior (seating and features)
• User interface and controls
• Infotainment system
• Lighting Systems
• Advanced Driver Assistance Systems (ADAS)
• Cargo Space and Towing

Performance

The Volkswagen ID.3 Pro S offers modest performance with a maximum power of 170 kW (231 hp / 228 bhp) and a total torque of 310 Nm (229 lb-ft). It accelerates from 0 to 100 km/h (0 to 62 mph) in 7.1 seconds and has a top speed of 160 km/h (99 mph), aligning more closely with traditional internal combustion engine vehicles.

Battery, Range, and Charging

The high-capacity battery has a gross capacity of 82.0 kWh and a net usable capacity of 77.0 kWh, providing a 5.0 kWh buffer (6.1%) for battery protection. With a nominal voltage of 350 volts, the system is classified as a 400-volt battery system, aligning with industry standards.

Under the WLTP (Worldwide Harmonized Light Vehicles Test Procedure) standard, the vehicle's range varies between 553 to 548 km (344-341 miles), depending on the specific configuration and options, such as wheel size. Larger wheels can increase energy consumption and subsequently reduce the overall range. The vehicle's energy consumption is rated at 13.9 kWh/100 km for the base model and 14.1 kWh/100 km for the top-tier model under the WLTP test cycle.For more details about the range, see real-world data and range listings on this model’s range and consumption page.

The vehicle supports fast DC charging with a maximum power of 175 kW. Charging from 0% to 100% takes approximately 64 minutes, while a typical 10% to 80% charge takes about 35 minutes with an average charging speed of 92 kW. Considering an additional 5 minutes for each charging stop due to driving interruptions, the optimal charging range is from 2% to 43%. This results in an effective charging speed, including time lost, of 100 kW, with each charging session taking about 19 minutes and 1 seconds.

In a 1000 km challenge at a constant speed of 120 km/h (75 mph) with an assumed consumption rate of 21 kWh/100 km, the trip would take about 9 hours and 41 minutes, needing four charging stops from 2% to 46%, totaling 82 minutes of charging time.

Onboard Charger

The standard onboard charger supports up to 11 kW for Level 1 and Level 2 AC charging, allowing a full 0–100% charge in about 7 hours and 0 minutes with a standard home setup.

Charge Port

The location of the charge port is on the right rear side. This placement makes it easy to use charging stations that require backing up to connect.

Connector types vary by market: this model uses CCS Combo 1 in North America and CCS Combo 2 in Europe. For complete specifications for all markets, refer to the full specifications.

Drivetrain

The Volkswagen ID.3 Pro S has a rear-wheel drive system supported by one motor on the rear axle. The motor used is Induction Motor.

Suspension

The standard suspension has steel springs with a fixed height but an optional damping adjustment.Ground clearance with this setup is 150 mm.

Steering

Progressive steering is optional on the Volkswagen ID.3 Pro S, automatically adjusting the steering ratio based on speed for improved control and comfort.

Brakes

The Volkswagen ID.3 Pro S uses disc brakes in the front for superior stopping power and heat dissipation, while drum brakes are employed in the rear for cost efficiency and durability. Drum brakes provide adequate performance for the rear wheels, require less maintenance, and integrate seamlessly with the vehicle's regenerative braking system. This combination ensures optimal braking performance and cost-effectiveness, aligning with the overall efficiency goals of the EV. The front discs are 358 mm.

Regenerative Braking

The regenerative braking system in this model offers several modes to enhance efficiency and driving experience. The most efficient option is the Automatic Regeneration Mode, where the vehicle coasts when possible and employs regenerative braking to reduce speed as needed.

Manual regeneration is another mode, where regenerative braking is controlled by pressing the brake pedal. The brake system blends in physical brakes only when necessary.

Another option is the Regen on Accelerator Pedal mode where regenerative braking is activated when the driver eases off the accelerator pedal. This system allows the vehicle to slow down and recover energy without the driver needing to press the brake pedal, a feature often referred to as one-pedal driving.

Interior

Seats

This model offers a four-seat layout or an optional 4+1 layout.

First Row Seats

The Volkswagen ID.3 Pro S offers a single type of front seat.

The following functionalities are available on the standard seat:

• Fore-and-aft adjustment (manually adjustable, electrically adjustable as an option)
• Height adjustable headrest
• Heating (optional)

Second Row Seat

The second row features a standard three-seat bench with a 60:40 split, allowing each section to fold separately to increase cargo space.

Additional functionalities include:

Climate System

Two climate system options are available:

• 1-zone climate system: Supports only controlling one shared zone for the whole car.
• 2-zone climate system: Supports different temperatures for the driver and passenger.

This model has a heat pump as an option. This heat pump can save significant energy used for heating in cold weather.

Comfort Features

The Volkswagen ID.3 Pro S includes several features to enhance comfort and convenience:;

• Wireless Phone Charging

User Interface and Control

Two different screen setups are available on the Volkswagen ID.3 Pro S.

The standard layout has the following configuration.

Behind the steering wheel is a digital instrument cluster mounted on the steering wheel column, and on top of the dashboard is an infotainment screen.

Key screen details:

• The screen on the steering column is 5.0 inches large
• The touch screen on the dashboard's center is 10.0 inches large

The optional layout has the following configuration.

Behind the steering wheel is a digital instrument cluster mounted on the steering wheel column, and on top of the dashboard is an infotainment screen.

Key screen details:

• The screen on the steering column is 5.0 inches large
• The touch screen on the dashboard's center is 12.0 inches large

A head-up display is common.optionalfeature system that projects speed and other important driver information onto the windshield.

Steering Wheel

The Volkswagen ID.3 Pro S is equipped with a single type of steering wheel:

• Circular Steering Wheel: This steering wheel provides intuitive control over the infotainment system, allowing you to easily adjust the volume, change music tracks, and manage other key functions.

Mirrors

Both the exterior and interior mirrors use conventional mirror technology to provide a clear view of the area behind the vehicle.

Infotainment

Navigation System

With the common.optionalfeature in-car navigation system, you have all the assistance you need to reach your destination effortlessly.

Phone Mirroring

The Volkswagen ID.3 Pro S supports Android Auto and Apple CarPlay, allowing you to mirror your phone's screen on the car's display. This functionality enables you to run apps like Google Maps or Waze directly from your phone.

Sound System

You can choose between two sound systems for the Volkswagen ID.3 Pro S:

• Sound system: Features five speakers and delivers a maximum output of 140 watts.
• Volkswagen Soundsystem: Features seven speakers and delivers a maximum output of 450 watts.

Additionally, the model includes 4 USB-C connections as standard.

Mobile App

The Volkswagen ID.3 Pro S comes with a dedicated mobile app, available for both Android and iOS devices, allowing you to manage and monitor your vehicle remotely. The app offers a wide range of features designed to enhance your driving experience:;

Lights

You can choose between two types of headlights for the Volkswagen ID.3 Pro S.

• Standard Headlights: These use advanced LED technology, providing bright and efficient illumination.
• LED Matrix Headlights: Available as an option, this adaptive system splits the traditional single headlight beam into dozens of smaller rays that the light controller can turn on and off individually, optimizing lighting by un-lighting specific small areas in front.

The taillights use LED technology, ensuring both high visibility and energy efficiency.

Advanced Driver Assistance Systems

The Volkswagen ID.3 Pro S features a range of standard and optional advanced driver assistance systems (ADAS) designed to enhance safety and comfort. ;

Efficiency Assist: A Standard feature that helps drivers anticipate driving conditions and conserve energy.

Safety Systems

Anti-lock Braking System (ABS): Standard on the Volkswagen ID.3 Pro S, this system prevents the wheels from locking during braking.

Electronic Stability Control (ESC): Standard on the Volkswagen ID.3 Pro S, this system improves the vehicle's stability and handling during sudden maneuvers or on slippery road conditions.

Lane-Keeping Assist (LKA): Standard on the Volkswagen ID.3 Pro S, this system helps prevent the vehicle from drifting out of its lane. It also includes a Lane Departure Warning system to alert the driver if the vehicle veers out of the lane.

Front Cross Traffic Assist (FCTA) : Standard on the Volkswagen ID.3 Pro S, this driver assist system that helps drivers detect oncoming traffic when crossing an intersection or turning left or right from a stopped position.

Forward Collision Warning (FCW): Standard on the Volkswagen ID.3 Pro S, this driver assist system helps drivers avoid or mitigate frontal collisions.

Automatic Emergency Braking (AEB): Standard on the Volkswagen ID.3 Pro S, this system autonomously applies the brakes to prevent or reduce the severity of a collision if the driver does not react in time.

Automatic Emergency Steering (AES): Standard on the Volkswagen ID.3 Pro S, this system assists in avoiding collisions by automatically steering the vehicle in an emergency.

Blind-spot Monitoring (BSM) : Optional on the Volkswagen ID.3 Pro S, this side assist system helps to detect traffic in blind spots.

Driving Automation

The Volkswagen ID.3 Pro S offers driving automation at levels 1 or 2, depending on the equipment level.

With the standard system the model offers no driving automation.

• Cruise control.

With the level 1 system, you get thadditional driving automation features to the ones listed above:

• Adaptive Cruise Control (ACC)

With the optional Assistantpackage plus level 2 system, you get additional driving automation features to the ones listed above:

• Lane Centering Assist (LCA) /AutoSteer: keeps the car in your lane and slows down if needed in traffic. The system limits how long you can drive without touching the steering wheel.
• Automatic parking. (optional)

Security and Access Technologies

The Volkswagen ID.3 Pro S is equipped with advanced security features to protect you and your vehicle. These include:

Keyless Entry and Start: With the standard keyless start and optional keyless entry, you can unlock and start the vehicle seamlessly without removing the key from your pocket or bag.

Cargo Capacity and Towing Ability

The trunk offers a cargo capacity of 385 liters (13.6 CU FT). With the rear seat folded down, this expands to 1267 liters (44.7 CU FT).

On the roof, you can load up to 0 kg (0.0 lbs).

The vehicle’s maximum weight is 2420 kg (5335 lbs), with a base weight of 1884 kg (4154 lbs). This allows for a maximum load of 536 kg (1182 lbs), including the driver and passengers. Note that some options may increase the base weight and reduce the maximum loading capacity.

This model is not available with a towbar. So, to pull a trailer, you must look at other models.
