Last modified: Nov 3, 2024
Tesla Model Y Performance specifications
EVKX.net gives you the full specifications for Tesla Model Y Performance.
Tesla Model Y Performance
Performance
| Spec | Value |
|---|---|
| Peak power | 393 KW (534 hp /527 bhp) |
| Electrical torque output | 660 nm (487 lb-ft) |
| Top speed | 250 kph (155 mph) |
| 0-100km/h (0-62 mph) | 3,7 s |
Range & Consumption
Below you see the offical range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the offical range values are measured.
| Spec | Value |
|---|---|
| WLTP range | 514 km |
| WLTP consumption | 14,6 kWh/100km |
| WLTP consumption with charging loss | 17,1 kWh/100km |
| EPA range | 285 mi |
| EPA consumption | 3,8 mi/kWh |
| Basic trim CLTC range | 615 km |
| Basic trim CLTC consumption | 12,2 kWh/100km |
Battery & Charging
| Spec | Value |
|---|---|
| Battery gross | 82 kWh |
| Battery net | 75 kWh |
| Max DC charging | 250 kW |
| Pack Configuration | 96s46p |
| Nominal voltage | 357 |
| Cathode Materials | NMC811 |
Chargeport
| Spec | Value |
|---|---|
| Chargeport placement | LeftRearCorner |
| Type chargeport Europe | CCS2 |
| Type chargeport North America | NACS |
| Type chargeport China | NACS |
| Type chargeport Japan | NACS |
| Type chargeport Oceania (Australia, New Zealand ++) | NACS |
Dimensions
| Spec | Value |
|---|---|
| Length | 4751 mm (187,0") |
| Height | 1624 mm (63,9") |
| Width excluding mirrors | 1921 mm (75,6") |
| Width including mirrors | 2129 mm (83,8") |
| Wheelbase | 2890 mm (113,8") |
| Track width front | 1636 mm (64,4") |
| Track width rear | 1636 mm (64,4") |
| Drag coefficient | 0,23 |
| Frontal area | 2,65 |
| Approach Angle | 9 |
| Departure Angle | 9,8 |
| Turning circle | 12,1 meter (476,4") |
Cargo Capacity and Towing Ability
| Spec | Value |
|---|---|
| Curb weight | 2135 kg (4707 lbs) |
| Maximum total weight | 2720 kg (5997 lbs) |
| Maximum load including weight driver | 585 kg (1290 lbs) |
| Maks roof cargo | 75 kg (165 lbs) |
| Trunk capacity | 854 liter (30 cu-ft) |
| Trunk capacity with all rear seats folded | 2158 liter (76 cu-ft) |
| Size frunk | 117 liter (4 cu-ft) |
| Max trailer weight braked | 1600 kg (3527 lbs) |
| Max trailer weight Un braked | 750 kg (1653 lbs) |
| Maximum tow ball weight | 75 kg (165 lbs) |
Suspension
| Spec | Value |
|---|---|
| Adaptive suspension | Not available |
| Adjustable damping front | Not available |
| Adjustable damping rear | Not available |
| Adjustable height front | Not available |
| Adjustable height rear | Not available |
| Max ground clearance | 167 mm (6,6") |
| Minimum ground clearance | 167 mm (6,6") |
| Damper type front | Monotube |
| Damper type rear | Monotube |
| Spring type front | Coil Spring |
| Spring type rear | Coil Spring |
| Suspension type front | Double wishbone suspension |
| Suspension type rear | Multi-link |
Interior
This model is available with a seat configuration with five or seven seats.
Front seats
standard
| Spec | Value |
|---|---|
| Seat type | Driver and Passenger Seat |
| Seat depth adjustment | Standard electric feature |
| Seat height adjustment | Standard electric feature |
| Backrest angle adjustment | Standard electric feature |
| Interior.Seatoptions.SeatCushionAngleAdjustment | Standard electric feature |
| Memory | Standard feature |
| Height adjustable headrest | Not Available |
| Length adjustable headrest | Not Available |
| Adjustable thigh support | Not Available |
| Backrest side bolster adjustment | Not Available |
| Seat cushion side bolster adjustement | Not Available |
| Footrest passengers | Not Available |
| Leg support passenger | Not Available |
| Electric lumbar adjustment | Not Available |
| Seat ventilation | Not Available |
| Massage function | Not Available |
Second row seats
standard
| Spec | Value |
|---|---|
| Seat type | Three-seat bench |
| Height adjustable headrest | Not Available |
| Length adjustable headrest | Not Available |
| Adjustable thigh support | Not Available |
| Backrest side bolster adjustment | Not Available |
| Seat cushion side bolster adjustement | Not Available |
| Footrest passengers | Not Available |
| Leg support passenger | Not Available |
| Electric lumbar adjustment | Not Available |
| Seat ventilation | Not Available |
| Massage function | Not Available |
Driver Assistance
| Spec | Value |
|---|---|
| Lane keeping | Yes, standard equipment |
| Lane departure warning | Yes, standard equipment |
| Drowsiness Alert | Yes, standard equipment |
| Reversing camera | Yes, optional equipment |
| 360 camera | Not available |
| Rear cross traffic alert | Not available |
| Rear parking sensors | Yes, standard equipment |
| Front parking sensors | Yes, standard equipment |
| Side parking sensors | Yes, standard equipment |
| Hill descent assist | Not available |
| Hill start assist | Not available |
| AntiLock Braking System | Yes, standard equipment |
| Automatic emergency braking | Yes, standard equipment |
| Traction control | Yes, standard equipment |
| Left turn crash avoidance | Not available |
| Forward Collision Warning | Yes, standard equipment |
| Electronic stability control | Yes, standard equipment |
| Temperature warning | Yes, standard equipment |
| Cross traffic assist | Yes, standard equipment |
| Efficiency assist | Not available |
| Automatic Emergency Steering | Yes, standard equipment |
| Traffic Sign Recognition | Yes, standard equipment |
| Night Vision | Not available |
UI and controls
| Spec | Value |
|---|---|
| Head-up display | Not available |
| Voice control | Yes, standard equipment |
| Gesture control | Not available |
| Android Auto support | Not available |
| Apple Carplay support | Not available |
| In Car navigation | Yes, standard equipment |
| Available screen layouts | 1 |
| Digital driver display | Not available |
| Infotainment screen | Yes, 15" |
| Front passenger Infotainment screen | Not available |
| Rear passenger Infotainment screen | Not available |
