Leapmotor C10 69kWh RWD specifications
Last modified: May 07, 2026
Specifications in progress
Some specifications for the Leapmotor C10 69kWh RWD are still being completed. Missing values will be added as they are confirmed.
EVKX.net provides full specifications for Leapmotor C10 69kWh RWD.
EVKX.net seeks to have the most complete specifications for Leapmotor C10 69kWh RWD. Click on image above for full article, visit the image gallery for high-res images of Leapmotor C10 69kWh RWD, visit the chargeinfo for Leapmotor C10 69kWh RWD with chargecurve, visit extended range info for real world ranges.
SUV · RWD · 5 seats · 400V architecture
Range
WLTP (Worldwide Harmonised Light Vehicles Test Procedure) is the European lab test used to rate range and consumption. Real-world range is usually lower.
420 km
WLTP
Battery
Usable (net) capacity is the energy actually available for driving. It is lower than the gross capacity, which keeps a protective buffer in reserve.
67 kWh
usable
DC charging
The highest DC fast-charging power the car can accept, in kW. It is only reached over part of the charging curve, not the whole session.
80 kW
max
0–100 km/h
7.29 s
Power
170 kW
231 hp
Efficiency
Energy used per 100 km. Lower is better — it means more range from the same battery.
16.0
kWh/100 km
Drivetrain
RWD
Leapmotor C10 69kWh RWD
Performance & Drivetrain
Performance
Acceleration, top speed, and power specifications
|
Spec
|
Value
|
|---|---|
| Peak power | 170 kW (231 hp / 228 bhp) |
| Electrical torque output | 320 Nm (236 lb-ft) |
| Top speed | 170 kph (106 mph) |
| 0-100km/h (0-62 mph) | 7.29 s |
Power & Torque
Peak power
170 kW (231 hp / 228 bhp)
Electrical torque output
320 Nm (236 lb-ft)
Speed & Acceleration
Top speed
170 kph (106 mph)
0-100km/h (0-62 mph)
7.29 s
Suspension
Spec
Value
Not available
Not available
Not available
Not available
Not available
180 mm (7.1")
180 mm (7.1")
Monotube
Monotube
Coil
Coil
MacPhersonStrut
Suspension type rear
Multilink
Adaptive Features
Not available
Not available
Not available
Height Adjustment
Not available
Not available
Ground Clearance
180 mm (7.1")
180 mm (7.1")
Component Types
Monotube
Monotube
Coil
Coil
MacPhersonStrut
Suspension type rear
Multilink
Battery, Range & Charging
Battery & Charging
Battery specifications and charging capabilities
|
Spec
|
Value
|
|---|---|
|
69.9
kWh
|
|
|
67
kWh
|
|
|
80
kW
|
|
|
Number of modules
|
|
|
320
V
|
|
|
Cathode Materials
|
LFP |
69.9
kWh
67
kWh
80
kW
Number of modules
320
V
Cathode Materials
LFP
Chargeport
Charging port specifications by region
|
Spec
|
Value
|
|---|---|
|
Chargeport placement
|
Left rear side |
|
Type chargeport Europe
|
CCS2
|
|
Type chargeport North America
|
CCS1
|
|
Type chargeport China
|
GBT
|
|
Type chargeport Japan
|
CHAdeMO
|
|
Type chargeport Oceania (Australia, New Zealand ++)
|
CCS2
|
Chargeport placement
Left rear side
Type chargeport Europe
CCS2
Type chargeport North America
CCS1
Type chargeport China
GBT
Type chargeport Japan
CHAdeMO
Type chargeport Oceania (Australia, New Zealand ++)
CCS2
Range & Consumption
Range estimates and energy consumption data
Below you see the official range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the official range values are measured.
|
Spec
|
Value
|
|---|---|
|
WLTP range
Learn more
|
420
km
|
|
WLTP consumption
Learn more
|
16.0
kWh/100km
|
|
WLTP consumption with charging loss
Learn more
|
kWh/100km
|
|
Basic trim CLTC range
Learn more
|
530
km
|
|
Basic trim CLTC consumption
Learn more
|
12.6
kWh/100km
|
Dimensions, Cargo & Exterior
Dimensions
Spec
Value
Length
4739 mm (186.6")
Height
1680 mm (66.1")
Width excluding mirrors
1900 mm (74.8")
Width including mirrors
2160 mm (85.0")
Wheelbase
2825 mm (111.2")
Track width front
1620 mm (63.8")
Track width rear
1625 mm (64.0")
Drag coefficient
0.29
Frontal area
2.67 m²
Approach Angle
17
Departure Angle
24
Turning circle
11.4 meter (448.8")
Basic Dimensions
Length
4739 mm (186.6")
Height
1680 mm (66.1")
Width excluding mirrors
1900 mm (74.8")
Width including mirrors
2160 mm (85.0")
Wheelbase & Track
Wheelbase
2825 mm (111.2")
Track width front
1620 mm (63.8")
Track width rear
1625 mm (64.0")
Aerodynamics
Drag coefficient
0.29
Frontal area
2.67 m²
Clearance & Turning
Approach Angle
17
Departure Angle
24
Turning circle
11.4 meter (448.8")
Cargo Capacity and Towing Ability
Weight, cargo capacity and towing specifications
|
Spec
|
Value
|
|---|---|
|
1940 kg (4277 lbs)
|
|
|
2315 kg (5104 lbs)
|
|
|
375 kg (827 lbs)
|
|
|
75 kg (165 lbs)
|
|
|
425 liter (15 cu-ft)
|
|
|
1410 liter (50 cu-ft)
|
|
|
Not available
|
|
|
Not available
|
|
|
Not available
|
|
|
Maximum tow ball weight
|
Not available
|
Weight Specifications
1940 kg (4277 lbs)
2315 kg (5104 lbs)
375 kg (827 lbs)
75 kg (165 lbs)
Cargo Capacity
425 liter (15 cu-ft)
1410 liter (50 cu-ft)
Not available
Towing Capacity
Not available
Not available
Maximum tow ball weight
Not available
Exterior
Spec
Value
Paint colors
Glazed green
Pearly White
Sky canopy gray
Metallic Black
Glacier Blue
Tundra Gray
Paint colors
Glazed green
Pearly White
Sky canopy gray
Metallic Black
Glacier Blue
Tundra Gray
Interior, Controls & Infotainment
Interior
Seating Configuration
This model is available with a seat configuration with five seats.
Front seats
Spec
Value
Driver and Passenger Seat
Seat depth adjustment
Standard electric feature
Seat height adjustment
Standard electric driver, not available passenger
Backrest angle adjustment
Standard electric feature
Seat cushion angle adjustment
Not Available
Memory
Unknown
Standard feature
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Optional feature
Not Available
Seat Category
Driver and Passenger Seat
Basic Adjustments
Seat depth adjustment
Standard electric feature
Seat height adjustment
Standard electric driver, not available passenger
Backrest angle adjustment
Standard electric feature
Memory
Unknown
Advanced Adjustments
Seat cushion angle adjustment
Not Available
Height adjustable headrest
Standard feature
Length adjustable headrest
Not Available
Adjustable thigh support
Not Available
Backrest side bolster adjustment
Not Available
Seat cushion side bolster adjustment
Not Available
Comfort Features
Footrest passenger
Not Available
Leg support passenger
Not Available
Electric lumbar adjustment
Not Available
Seat ventilation
Optional feature
Massage function
Not Available
Second row seats
Spec
Value
Three-seat bench
Seat depth adjustment
Not Available
Seat height adjustment
Not Available
Backrest angle adjustment
Standard feature
Seat cushion angle adjustment
Not Available
Memory
Not Available
Standard feature
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Not Available
Seat Category
Seat type
Three-seat bench
Basic Adjustments
Seat depth adjustment
Not Available
Seat height adjustment
Not Available
Backrest angle adjustment
Standard feature
Memory
Not Available
Advanced Adjustments
Seat cushion angle adjustment
Not Available
Height adjustable headrest
Standard feature
Length adjustable headrest
Not Available
Adjustable thigh support
Not Available
Backrest side bolster adjustment
Not Available
Seat cushion side bolster adjustment
Not Available
Comfort Features
Footrest passenger
Not Available
Leg support passenger
Not Available
Electric lumbar adjustment
Not Available
Seat ventilation
Not Available
Massage function
Not Available
Center consoles
First row center console
Console design
Split level console
UI and controls
User interface and control specifications
|
Spec
|
Value
|
|---|---|
| Head-up display | Not available |
| Voice control | Yes, standard equipment |
| Gesture control | Not available |
| Android Auto support | Not available |
| Apple CarPlay support | Not available |
| In-car navigation | Yes, standard equipment |
| Available screen layouts | 1 |
Interface Controls
Head-up display
Not available
Voice control
Yes, standard equipment
Gesture control
Not available
Available screen layouts
1
Smartphone Integration
Not available
Not available
Yes, standard equipment
Infotainment
Spec
Value
Number of speakers
12
Total effect
840 W
Audio System
Number of speakers
12
Total effect
840 W
Driver Assistance
Driver Assistance
Advanced safety and driving assistance features
|
Spec
|
Value
|
|---|---|
| Yes, standard equipment | |
| Yes, standard equipment | |
| Yes, optional equipment | |
| Yes, standard equipment | |
| Yes, standard equipment | |
| Yes, standard equipment | |
|
Hill descent assist
|
Yes, standard equipment |
|
Hill start assist
|
Yes, standard equipment |
| Yes, standard equipment | |
| Yes, standard equipment | |
|
Traction control
|
Yes, standard equipment |
|
Left turn crash avoidance
|
Yes, standard equipment |
| Yes, standard equipment | |
| Yes, standard equipment | |
|
Temperature warning
|
Yes, standard equipment |
| Yes, standard equipment | |
| Not available | |
| Not available | |
| Yes, standard equipment | |
| Not available |
Yes, standard equipment
Yes, standard equipment
Yes, optional equipment
Yes, standard equipment
Yes, standard equipment
Sensors & Cameras
Vehicle sensors and camera systems
|
Spec
|
Value
|
|---|---|
|
|
|
|
|
|
|
|
|
ADAS processors
|
|
On bumper front
((Optional))
On bumper front
((Optional))
On bumper front left corner
((Optional))
On bumper front right corner
((Optional))
On bumper front left side
((Optional))
On bumper front right side
((Optional))
On bumper rear left side
((Optional))
On bumper rear right side
((Optional))
On bumper rear left corner
On bumper rear right corner
On bumper rear
On bumper rear
Top center windshield
Left front side
Right front side
Front
((Optional))
On left wing mirror
((Optional))
On right wing mirror
((Optional))
Rear center
((Optional))
Front
((Optional))
Left front corner
((Optional))
Right front corner
((Optional))
Left rear corner
((Optional))
Right rear corner
((Optional))
Center roof over windshield
((Optional))
Qualcomm Snapdragon 8195
— 30 TOPS
