Ford Mustang Mach-E GT specifications

EVKX.net gives you the full specifications for Ford Mustang Mach-E GT.

EVKX.net seeks to have the most complete specifications for Ford Mustang Mach-E GT. Click on image above for full article, visit the image gallery for high-res images of Ford Mustang Mach-E GT, visit the chargeinfo for Ford Mustang Mach-E GT with chargecurve, vist extended range info for real world ranges.

Performance

Spec	Value
Peak power	358 KW (487 hp /480 bhp)
Electrical torque output	860 nm (635 lb-ft)
Top speed	200 nm (124 lb-ft)
0-100km/h (0-62 mph)	3.7 s

Range & Consumption

Below you see the offical range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the offical range values are measured.

Spec	Value
WLTP range	490 km
WLTP consumption	18.8 kWh/100km
WLTP consumption with charging loss	188 kWh/100km

Battery & Charging

Spec	Value
Battery gross	98.8 kWh
Battery net	92 kWh
Max DC charging	150 kW
Number of modules
Pack Configuration	94s4p
Nominal voltage	376 V
Cathode Materials	NMC

Chargeport

Spec	Value
Spec	LeftFrontSide
Type chargeport Europe	CCS2
Type chargeport North America	CCS1
Type chargeport China	GBT
Type chargeport Japan	CHAdeMO
Type chargeport Oceania (Australia, New Zealand ++)	CCS2

Dimensions

Spec	Value
Length	4713 mm (185.6")
Height	1624 mm (63.9")
Width excluding mirrors	1881 mm (74.1")
Width including mirrors	2091 mm (82.3")
Wheelbase	2984 mm (117.5")
Track width front	1613 mm (63.5")
Track width rear	1610 mm (63.4")
Drag coefficient	0.30
Frontal area	m²
Approach Angle
Departure Angle
Turning circle	11.6 meter (456.7")

Cargo Capacity and Towing Ability

Spec	Value
Curb weight	2218 kg (4890 lbs)
Maximum total weight	2690 kg (5930 lbs)
Maximum load including weight driver	472 kg (1041 lbs)
Maks roof cargo	75 kg (165 lbs)
Trunk capacity	402 liter (14 cu-ft)
Trunk capacity with all rear seats folded	1420 liter (50 cu-ft)
Size frunk	100 liter (4 cu-ft)
Max trailer weight braked	750 kg (1653 lbs)
Max trailer weight Un braked	750 kg (1653 lbs)
Maximum tow ball weight	30 kg (66 lbs)

Suspension

Spec	Value
Adaptive suspension	Yes, standard equipment
Adjustable damping front	Yes, standard equipment
Adjustable damping rear	Yes, standard equipment
Adjustable height front	Not available
Adjustable height rear	Not available
Max ground clearance	147 mm (5.8")
Minimum ground clearance	147 mm (5.8")
Damper type front	ElectronicallyControlled
Damper type rear	ElectronicallyControlled
Spring type front	Coil
Spring type rear	Coil
Suspension type front	MacPhersonStrut
Suspension type rear	Multilink

Interior

This model is available with a seat configuration with five seats.

Front seats

standard

Spec	Value
Seat type	Driver and Passenger Seat
Seat depth adjustment	Standard electric feature
Seat height adjustment	Standard electric feature
Backrest angle adjustment	Standard electric feature
Seat cushion angle adjustment	Not Available
Memory	Standard driver, not available passenger
Height adjustable headrest	Standard feature
Length adjustable headrest	Not Available
Adjustable thigh support	Not Available
Backrest side bolster adjustment	Not Available
Seat cushion side bolster adjustement	Not Available
Footrest passengers	Not Available
Leg support passenger	Unknown
Electric lumbar adjustment	Standard electric feature
Seat ventilation	Not Available
Massage function	Not Available

Second row seats

standard

Spec	Value
Seat type	Three-seat bench
Seat depth adjustment	Unknown
Seat height adjustment	Unknown
Backrest angle adjustment	Unknown
Seat cushion angle adjustment	Not Available
Memory	Not Available
Height adjustable headrest	Standard feature
Length adjustable headrest	Not Available
Adjustable thigh support	Not Available
Backrest side bolster adjustment	Not Available
Seat cushion side bolster adjustement	Not Available
Footrest passengers	Not Available
Leg support passenger	Not Available
Electric lumbar adjustment	Not Available
Seat ventilation	Not Available
Massage function	Not Available

Driver Assistance

Spec	Value
Lane keeping	Yes, standard equipment
Lane departure warning	Yes, standard equipment
Drowsiness Alert
Reversing camera	Yes, standard equipment
360 camera	Yes, standard equipment
Rear cross traffic alert	Yes, standard equipment
Hill descent assist
Hill start assist	Yes, standard equipment
AntiLock Braking System	Yes, standard equipment
Automatic emergency braking	Yes, standard equipment
Traction control	Yes, standard equipment
Left turn crash avoidance
Forward Collision Warning	Yes, standard equipment
Electronic stability control	Yes, standard equipment
Temperature warning
Cross traffic assist	Yes, standard equipment
Efficiency assist
Automatic Emergency Steering	Yes, standard equipment
Traffic Sign Recognition	Yes, optional equipment
Night Vision	Not available

Sensors & Cameras

Spec	Value
Ultrasonic sensors
Cameras
Radar sensors
Lidar sensors

UI and controls

Spec	Value
Head-up display
Voice control
Gesture control
Android Auto support	Yes, standard equipment
Apple Carplay support	Yes, standard equipment
In Car navigation	Yes, standard equipment
Available screen layouts	1
Digital driver display	Yes, 10.2
Infotainment screen	Yes, 15.5"
Front passenger Infotainment screen	Not available
Rear passenger Infotainment screen	Not available

B&O Sound System

Spec	Value
Number of speakers	10
Number of speakers	560

Exterior

Spec	Value
Paint colors	Absolute Black Vapor Blue Grabber Blue Space White Star White Rapid Red Carbonized Gray Cyber Orange
