Tesla Model X Standard Range specifications

EVKX.net gives you the full specifications for Tesla Model X Standard Range.

EVKX.net seeks to have the most complete specifications for Tesla Model X Standard Range. Click on image above for full article, visit the image gallery for high-res images of Tesla Model X Standard Range, visit the chargeinfo for Tesla Model X Standard Range with chargecurve, vist extended range info for real world ranges.

Performance

Spec	Value
Peak power	381 KW (518 hp /511 bhp)
Electrical torque output	700 nm (517 lb-ft)
Top speed	250 kph (155 mph)
0-100km/h (0-62 mph)	4,2 s

Range & Consumption

Below you see the offical range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the offical range values are measured.

Spec	Value
Basic trim WLTP range	543 km
Basic trim WLTP consumption	13,8 kWh/100km
Basic trim WLTP consumption with charging loss	20,8 kWh/100km
Top trim WLTP range	528 km
Top trim WLTP consumption	14,2 kWh/100km
Top trim WLTP consumption with charging loss	21,4 kwh/100km

Battery & Charging

Spec	Value
Battery gross	100 kWh
Battery net	75 kWh
Max DC charging	250 kW
Pack Configuration	110s72p
Nominal voltage	407

Chargeport

Spec	Value
Chargeport placement	LeftRearCorner
Type chargeport Europe	CCS2
Type chargeport North America	NACS
Type chargeport China	NACS
Type chargeport Japan	NACS
Type chargeport Oceania (Australia, New Zealand ++)	NACS

Dimensions

Spec	Value
Length	5057 mm (199,1")
Height	1680 mm (66,1")
Width excluding mirrors	1999 mm (78,7")
Width including mirrors	2271 mm (89,4")
Wheelbase	2965 mm (116,7")
Track width front	1690 mm (66,5")
Track width rear	1690 mm (66,5")
Drag coefficient	0,208
Turning circle	12,3 meter (484,3")

Cargo Capacity and Towing Ability

Spec	Value
Curb weight	2464 kg (5432 lbs)
Maximum total weight	2970 kg (6548 lbs)
Maximum load including weight driver	506 kg (1116 lbs)
Maks roof cargo	0 kg (0 lbs)
Trunk capacity	709 liter (25 cu-ft)
Trunk capacity with all rear seats folded	1828 liter (65 cu-ft)
Size frunk	183 liter (6 cu-ft)
Max trailer weight braked	2250 kg (4960 lbs)
Max trailer weight Un braked	750 kg (1653 lbs)
Maximum tow ball weight	100 kg (220 lbs)

Suspension

Spec	Value
Adaptive suspension	Yes, standard equipment
Adjustable damping front	Yes, standard equipment
Adjustable damping rear	Yes, standard equipment
Adjustable height front	Yes, standard equipment
Adjustable height rear	Yes, standard equipment
Max ground clearance	158 mm (6,2")
Minimum ground clearance	117 mm (4,6")
Damper type front	ElectronicallyControlled
Damper type rear	ElectronicallyControlled
Spring type front	Air
Spring type rear	Air

Interior

Interior.Seatlayout.OnlySix

Front seats

standard

Spec	Value
Seat type	Driver and Passenger Seat
Seat depth adjustment	Standard electric feature
Seat height adjustment	Unknown
Backrest angle adjustment	Unknown
Interior.Seatoptions.SeatCushionAngleAdjustment	Unknown
Memory	Standard feature
Height adjustable headrest	Standard feature
Length adjustable headrest	Not Available
Adjustable thigh support	Not Available
Backrest side bolster adjustment	Not Available
Seat cushion side bolster adjustement	Not Available
Footrest passengers	Unknown
Leg support passenger	Unknown
Electric lumbar adjustment	Not Available
Seat ventilation	Standard feature
Massage function	Not Available

Second row seats

standard

Spec	Value
Seat type	Three-seat bench
Height adjustable headrest	Unknown
Length adjustable headrest	Unknown
Adjustable thigh support	Unknown
Backrest side bolster adjustment	Unknown
Seat cushion side bolster adjustement	Unknown
Footrest passengers	Unknown
Leg support passenger	Unknown
Electric lumbar adjustment	Unknown
Seat ventilation	Unknown
Massage function	Unknown

Driver Assistance

Spec	Value
Lane keeping	Yes, standard equipment
Lane departure warning	Yes, standard equipment
Drowsiness Alert	Yes, standard equipment
Reversing camera	Yes, optional equipment
360 camera	Not available
Rear cross traffic alert	Not available
Hill descent assist	Not available
Hill start assist	Not available
AntiLock Braking System	Yes, standard equipment
Automatic emergency braking	Yes, standard equipment
Traction control	Yes, standard equipment
Left turn crash avoidance	Not available
Forward Collision Warning	Yes, standard equipment
Electronic stability control	Yes, standard equipment
Temperature warning	Yes, standard equipment
Cross traffic assist	Yes, standard equipment
Efficiency assist	Not available
Automatic Emergency Steering	Yes, standard equipment
Traffic Sign Recognition	Yes, standard equipment
Night Vision	Not available

Sensors & Cameras

Spec	Value
Ultrasonic sensors
Cameras
Radar sensors
Lidar sensors

UI and controls

Spec	Value
Head-up display	Not available
Voice control
Gesture control
Android Auto support	Not available
Apple Carplay support	Not available
In Car navigation	Yes, standard equipment
Available screen layouts	1
Digital driver display	Yes, 12,3
Infotainment screen	Yes, 17"
Front passenger Infotainment screen	Not available
Rear passenger Infotainment screen	Not available

Exterior

Spec	Value
Paint colors	Pearl White Solid Black Midnight Silver Metallic Deep Blue Metallic (Silver) Red Multi-Coat
