Smart #5 Summit Edition specifications

Last modified: Nov 22, 2025

EVKX.net provides full specifications for Smart #5 Summit Edition.

EVKX.net seeks to have the most complete specifications for Smart #5 Summit Edition. Click on image above for full article, visit the image gallery for high-res images of Smart #5 Summit Edition, visit the chargeinfo for Smart #5 Summit Edition with chargecurve, visit extended range info for real world ranges.
Smart #5 Summit Edition

Smart #5 Summit Edition

Performance

Power, torque and acceleration specifications

Power & Torque

Peak power
Power
475 KW (646 hp /637 bhp)
Electrical torque output
Torque
710 nm (524 lb-ft)

Speed & Acceleration

Top speed
Top Speed
210 kph (131 mph)
0-100km/h (0-62 mph)
0-100 km/h
3.8 s
0-100km/h (0-62 mph) boost
Boost Mode
0 s

Range & Consumption

Official test cycle results and real-world estimates

Below you see the offical range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the offical range values are measured.
WLTP range
540 km
WLTP
WLTP consumption
17.4 kWh/100km
Real-world
WLTP consumption with charging loss
19.9 kWh/100km
WLTP
Basic trim CLTC range
660 km
CLTC
Basic trim CLTC consumption
14.2 kWh/100km
Real-world

Battery & Charging

Battery specifications and charging capabilities

Battery gross
100 kWh
Gross
Battery net
94 kWh
Usable
Max DC charging
430 kW
Peak DC
Number of modules
0
Pack Configuration
186s1p
Nominal voltage
685 V
Cathode Materials
NMC

Chargeport

Charging port specifications by region

Spec
LeftRearSide
Type chargeport Europe
CCS2
Europe

Dimensions

📏 Basic Dimensions

📏 Length
4695 mm (184.8")
📐 Height
1705 mm (67.1")
↔️ Width excluding mirrors
2169 mm (85.4")
🔄 Width including mirrors
1920 mm (75.6")

🛞 Wheelbase & Track

🛞 Wheelbase
2900 mm (114.2")
⚪ Track width front
1653 mm (65.1")
⚫ Track width rear
1658 mm (65.3")

💨 Aerodynamics

💨 Drag coefficient
0.3
📐 Frontal area
m²

⛰️ Clearance & Turning

⛰️ Approach Angle
18
🏔️ Departure Angle
21
🔄 Turning circle
11.2 meter (440.9")

Cargo Capacity and Towing Ability

Weight, cargo capacity and towing specifications

Weight Specifications

Curb weight
Empty Weight
2303 kg (5077 lbs)
2880 kg (6349 lbs)
577 kg (1272 lbs)
73 kg (161 lbs)

Cargo Capacity

630 liter (22 cu-ft)
1530 liter (54 cu-ft)
47 liter (2 cu-ft)

Towing Capacity

1600 kg (3527 lbs)
750 kg (1653 lbs)
Maximum tow ball weight
Tongue
100 kg (220 lbs)

Suspension

🎛️ Adaptive Features

🎛️ Adaptive suspension
Not available
🔧 Adjustable damping front
Not available
🔧 Adjustable damping rear
Not available

📏 Height Adjustment

📏 Adjustable height front
Not available
📏 Adjustable height rear
Not available

⬆️ Ground Clearance

⬆️ Max ground clearance
186 mm (7.3")
⬇️ Minimum ground clearance
186 mm (7.3")

🔩 Component Types

🔩 Damper type front
FrequencySelectiveDamping
🔩 Damper type rear
FrequencySelectiveDamping
🌀 Spring type front
Coil
🌀 Spring type rear
Coil
⚙️ Suspension type front
DoubleWishbone
⚙️ Suspension type rear
Multilink

Interior

💺 Seating Configuration
This model is available with a seat configuration with five seats.

🪑 Front seats

🏷️ Seat Category

🏷️ Seat type
Driver and Passenger Seat

⚙️ Basic Adjustments

↔️ Seat depth adjustment
Standard electric feature
↕️ Seat height adjustment
Standard electric feature
⤴️ Backrest angle adjustment
Standard electric feature
💾 Memory
Standard feature

🎛️ Advanced Adjustments

📐 Seat cushion angle adjustment
Not Available
🎚️ Height adjustable headrest
Standard feature
📏 Length adjustable headrest
Not Available
🦵 Adjustable thigh support
Not Available
🔄 Backrest side bolster adjustment
Not Available
🔁 Seat cushion side bolster adjustment
Not Available

💆 Comfort Features

🦶 Footrest passenger
Not Available
🔧 Leg support passenger
Standard passenger seat
⚡ Electric lumbar adjustment
Standard electric feature
🌬️ Seat ventilation
Standard feature
💆 Massage function
Standard feature

🚗 Second row seats

🏷️ Seat Category

🏷️ Seat type
Three-seat bench

⚙️ Basic Adjustments

↔️ Seat depth adjustment
Not Available
↕️ Seat height adjustment
Not Available
⤴️ Backrest angle adjustment
Standard electric feature
💾 Memory
Not Available

🎛️ Advanced Adjustments

📐 Seat cushion angle adjustment
Not Available
🎚️ Height adjustable headrest
Standard feature
📏 Length adjustable headrest
Not Available
🦵 Adjustable thigh support
Not Available
🔄 Backrest side bolster adjustment
Not Available
🔁 Seat cushion side bolster adjustment
Not Available

💆 Comfort Features

🦶 Footrest passenger
Not Available
🔧 Leg support passenger
Not Available
⚡ Electric lumbar adjustment
Not Available
🌬️ Seat ventilation
Not Available
💆 Massage function
Not Available

Driver Assistance

Advanced safety and driving assistance features

Lane keeping
Yes, standard equipment
Lane departure warning
Yes, standard equipment
Drowsiness Alert
Yes, standard equipment
Reversing camera
Yes, standard equipment
360 camera
Yes, standard equipment

Sensors & Cameras

Vehicle sensors and camera systems

Ultrasonic sensors
On bumper rear left side
On bumper rear right side
On bumper rear left corner
On bumper rear right corner
On bumper rear
On bumper rear
On bumper front left side
On bumper front right side
On bumper front left corner
On bumper front right corner
On bumper front
On bumper front
Cameras
Top center windshield
Rear center
On left wing mirror
On right wing mirror
Front
Radar sensors
Front
Left front corner
Right front corner
Left rear corner
Right rear corner
Lidar sensors
N/A

UI and controls

User interface and control specifications

Interface Controls

Head-up display
HUD
Yes, standard equipment
Voice control
Voice
Yes, standard equipment
Gesture control
Gesture
Not available
Available screen layouts
Layouts
1

Smartphone Integration

Yes, standard equipment
Yes, standard equipment
Yes, standard equipment

Infotainment

🎵 Audio System

🔊 Number of speakers
9
⚡ Total effect
200 W

Exterior

🎨 Paint colors

Terra Green Matte
