Porsche Taycan Turbo (GEN1) specifications

EVKX.net gives you the full specifications for Porsche Taycan Turbo (GEN1).

EVKX.net seeks to have the most complete specifications for Porsche Taycan Turbo (GEN1). Click on image above for full article, visit the image gallery for high-res images of Porsche Taycan Turbo (GEN1), visit the chargeinfo for Porsche Taycan Turbo (GEN1) with chargecurve, vist extended range info for real world ranges.

Performance

Spec	Value
Peak power	460 KW (625 hp /617 bhp)
Peak power with boost	500 KW (680 hp /671 bhp)
Electrical torque output boost	850 Nm
Top speed	260 kph (162 mph)
0-100km/h (0-62 mph) boost	3,2 s

Range & Consumption

Below you see the offical range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the offical range values are measured.

Spec	Value
Basic trim WLTP range	507 km
Basic trim WLTP consumption	16,5 kWh/100km
Basic trim WLTP consumption with charging loss	20,2 kWh/100km
Top trim WLTP range	435 km
Top trim WLTP consumption	19,2 kWh/100km
Top trim WLTP consumption with charging loss	23,6 kwh/100km

Battery & Charging

Spec	Value
Battery gross	93,4 kWh
Battery net	83,7 kWh
Max DC charging	270 kW
Number of modules	33
Pack Configuration	198s2p
Nominal voltage	725
Cathode Materials	NMC

Chargeports

Spec	Value
Chargeport placement	RightFrontSide
Type chargeport Europe	CCS2
Type chargeport North America	CCS1
Type chargeport China	GBT
Type chargeport Japan	CHAdeMO
Type chargeport Oceania (Australia, New Zealand ++)	CCS2

Spec	Value
Chargeport placement	LeftFrontSide
Type chargeport Europe	Type2
Type chargeport North America	J1772
Type chargeport China	GBT
Type chargeport Japan	CHAdeMO
Type chargeport Oceania (Australia, New Zealand ++)	CCS2

Dimensions

Spec	Value
Length	4963 mm (195,4")
Height	1381 mm (54,4")
Width excluding mirrors	1966 mm (77,4")
Width including mirrors	2144 mm (84,4")
Wheelbase	2900 mm (114,2")
Track width front	1710 mm (67,3")
Track width rear	1694 mm (66,7")
Drag coefficient	0,24
Frontal area	2,35
Approach Angle	13
Departure Angle	16,4
Turning circle	11,7 meter (460,6")

Cargo Capacity and Towing Ability

Spec	Value
Curb weight	2220 kg (4894 lbs)
Maximum total weight	2870 kg (6327 lbs)
Maximum load including weight driver	650 kg (1433 lbs)
Maks roof cargo	75 kg (165 lbs)
Trunk capacity	366 liter (13 cu-ft)
Size frunk	84 liter (3 cu-ft)

Suspension

Spec	Value
Adaptive suspension	Yes, standard equipment
Adjustable damping front	Yes, standard equipment
Adjustable damping rear	Yes, standard equipment
Adjustable height front	Yes, standard equipment
Adjustable height rear	Yes, standard equipment
Max ground clearance	128 mm (5,0")
Minimum ground clearance	103 mm (4,1")
Damper type front	ElectronicallyControlled
Damper type rear	ElectronicallyControlled
Spring type front	Air
Spring type rear	Air
Suspension type front	Double wishbone suspension
Suspension type rear	Multi-link

Interior

This model is available with a seat configuration with five seats.

Front seats

Comfort

Spec	Value
Seat type	Driver and Passenger Seat
Seat depth adjustment	Standard electric feature
Seat height adjustment	Unknown
Backrest angle adjustment	Unknown
Interior.Seatoptions.SeatCushionAngleAdjustment	Unknown
Memory	Unknown
Height adjustable headrest	Not Available
Length adjustable headrest	Not Available
Adjustable thigh support	Not Available
Backrest side bolster adjustment	Not Available
Seat cushion side bolster adjustement	Not Available
Footrest passengers	Unknown
Leg support passenger	Unknown
Electric lumbar adjustment	Standard electric feature
Seat ventilation	Not Available
Massage function	Not Available

Comfortseats with memory

Spec	Value
Seat type	Driver and Passenger Seat
Seat depth adjustment	Standard electric feature
Seat height adjustment	Unknown
Backrest angle adjustment	Unknown
Interior.Seatoptions.SeatCushionAngleAdjustment	Unknown
Memory	Unknown
Height adjustable headrest	Not Available
Length adjustable headrest	Not Available
Adjustable thigh support	Standard feature
Backrest side bolster adjustment	Not Available
Seat cushion side bolster adjustement	Not Available
Footrest passengers	Unknown
Leg support passenger	Unknown
Electric lumbar adjustment	Standard electric feature
Seat ventilation	Not Available
Massage function	Not Available

Sportsseats Plus

Spec	Value
Seat type	Driver and Passenger Seat
Seat depth adjustment	Standard electric feature
Seat height adjustment	Unknown
Backrest angle adjustment	Unknown
Interior.Seatoptions.SeatCushionAngleAdjustment	Unknown
Memory	Standard feature
Height adjustable headrest	Not Available
Length adjustable headrest	Not Available
Adjustable thigh support	Standard feature
Backrest side bolster adjustment	Standard feature
Seat cushion side bolster adjustement	Standard feature
Footrest passengers	Unknown
Leg support passenger	Unknown
Electric lumbar adjustment	Standard electric feature
Seat ventilation	Standard feature
Massage function	Optional feature

Second row seats

Standard

Spec	Value
Seat type	TwoIntegratedSeatBench
Height adjustable headrest	Not Available
Length adjustable headrest	Not Available
Adjustable thigh support	Not Available
Backrest side bolster adjustment	Not Available
Seat cushion side bolster adjustement	Not Available
Footrest passengers	Unknown
Leg support passenger	Unknown
Electric lumbar adjustment	Not Available
Seat ventilation	Not Available
Massage function	Not Available

2+1

Spec	Value
Seat type	TwoPlusOneIntegratedSeatBench
Height adjustable headrest	Not Available
Length adjustable headrest	Not Available
Adjustable thigh support	Not Available
Backrest side bolster adjustment	Not Available
Seat cushion side bolster adjustement	Not Available
Footrest passengers	Unknown
Leg support passenger	Unknown
Electric lumbar adjustment	Not Available
Seat ventilation	Not Available
Massage function	Not Available

Driver Assistance

Spec	Value
Lane keeping	Yes, standard equipment
Lane departure warning	Yes, standard equipment
Drowsiness Alert	Yes, standard equipment
Reversing camera	Yes, optional equipment
360 camera	Yes, optional equipment
Rear cross traffic alert	Yes (Cross traffic assist rear), optional equipment
Hill descent assist	Yes, standard equipment
Hill start assist	Yes, standard equipment
AntiLock Braking System	Yes, standard equipment
Automatic emergency braking	Yes, standard equipment
Traction control	Yes, standard equipment
Left turn crash avoidance	Yes, optional equipment
Forward Collision Warning	Yes, optional equipment
Electronic stability control	Yes, standard equipment
Temperature warning	Yes, standard equipment
Cross traffic assist	Yes, optional equipment
Efficiency assist	Yes, standard equipment
Automatic Emergency Steering	Yes, standard equipment
Traffic Sign Recognition	Yes, optional equipment
Night Vision	Yes (Night Vision Assist), optional equipment

Sensors & Cameras

Spec	Value
Ultrasonic sensors
Cameras
Radar sensors
Lidar sensors

UI and controls

Spec	Value
Head-up display	Yes, optional equipment
Voice control
Gesture control
Android Auto support	Yes, optional equipment
Apple Carplay support	Yes, optional equipment
In Car navigation	Yes, standard equipment
Available screen layouts	1
Digital driver display	Yes, 16,8
Infotainment screen	Yes, two 10,9" and 8,4"
Front passenger Infotainment screen	Yes, 10,9"
Rear passenger Infotainment screen	Not available

Number of avaiable sound systems3

Porsche Sound system

Spec	Value
Number of speakers	10
Total effect	150

BOSE® Surround Sound System

Spec	Value
Number of speakers	14
Total effect	710

Burmester® 3D High-End Surround Sound System

Spec	Value
Number of speakers	21
Total effect	1455

Exterior

Spec	Value
Paint colors	White Black Jet Black Metallic Volcano Grey Metallic (Gray) Carrara White Metallic Gentian Blue Metallic Dolomite Silver Metallic Mamba Green Metallic Frozen Blue Metallic Mahogany Metallic (Brown) Frozen Berry Metallic (Lilac) Cherry Metallic (Red) Coffee Beige Metallic Carmine Red Neptune Blue Crayon (Gray) Ice Grey Metallic (Gray)
