MG IM5 Performance specifications

MY2026
Last modified: Jan 04, 2026

EVKX.net provides full specifications for MG IM5 Performance.

EVKX.net seeks to have the most complete specifications for MG IM5 Performance. Click on image above for full article, visit the image gallery for high-res images of MG IM5 Performance, visit the chargeinfo for MG IM5 Performance with chargecurve, visit extended range info for real world ranges.
MG IM5 Performance

MG IM5 Performance

Performance

Power, torque and acceleration specifications

Power & Torque

Peak power
Power
553 KW (752 hp /742 bhp)
Electrical torque output
Torque
802 nm (592 lb-ft)

Speed & Acceleration

Top speed
Top Speed
238 kph (148 mph)
0-100km/h (0-62 mph)
0-100 km/h
3.2 s

Range & Consumption

Official test cycle results and real-world estimates

Below you see the offical range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the offical range values are measured.
WLTP range
575 km
WLTP
WLTP consumption
16.8 kWh/100km
Real-world
WLTP consumption with charging loss
19.7 kWh/100km
WLTP

Battery & Charging

Battery specifications and charging capabilities

Battery gross
100 kWh
Gross
Battery net
96.5 kWh
Usable
Max DC charging
396 kW
Peak DC
Number of modules
0
Pack Configuration
204s1p
Nominal voltage
751 V
Cathode Materials
NMC

Chargeport

Charging port specifications by region

Spec
LeftRearCorner
Type chargeport Europe
CCS2
Europe

Dimensions

📏 Basic Dimensions

📏 Length
4931 mm (194.1")
📐 Height
1474 mm (58.0")
↔️ Width excluding mirrors
1960 mm (77.2")
🔄 Width including mirrors
2077 mm (81.8")

🛞 Wheelbase & Track

🛞 Wheelbase
2950 mm (116.1")
⚪ Track width front
1698 mm (66.9")
⚫ Track width rear
1707 mm (67.2")

💨 Aerodynamics

💨 Drag coefficient
0.237
📐 Frontal area
m²

⛰️ Clearance & Turning

⛰️ Approach Angle
14
🏔️ Departure Angle
18
🔄 Turning circle
9.98 meter (392.9")

Cargo Capacity and Towing Ability

Weight, cargo capacity and towing specifications

Weight Specifications

Curb weight
Empty Weight
2298 kg (5066 lbs)
2730 kg (6019 lbs)
432 kg (952 lbs)
0 kg (0 lbs)

Cargo Capacity

457 liter (16 cu-ft)
1290 liter (46 cu-ft)
18 liter (1 cu-ft)

Towing Capacity

1500 kg (3307 lbs)
750 kg (1653 lbs)
Maximum tow ball weight
Tongue
75 kg (165 lbs)

Suspension

The model offers 2 suspension variants

🔧 Standard

🎛️ Adaptive Features

🎛️ Adaptive suspension
Not available
🔧 Adjustable damping front
Yes, standard equipment
🔧 Adjustable damping rear
Yes, standard equipment

📏 Height Adjustment

📏 Adjustable height front
Not available
📏 Adjustable height rear
Not available

⬆️ Ground Clearance

⬆️ Max ground clearance
151 mm (5.9")
⬇️ Minimum ground clearance
151 mm (5.9")

🔩 Component Types

🔩 Damper type front
Monotube
🔩 Damper type rear
Monotube
🌀 Spring type front
Coil
🌀 Spring type rear
Coil
⚙️ Suspension type front
DoubleWishbone
⚙️ Suspension type rear
Multilink

🔧 Air Suspension

🎛️ Adaptive Features

🎛️ Adaptive suspension
Yes, standard equipment
🔧 Adjustable damping front
Yes, standard equipment
🔧 Adjustable damping rear
Yes, standard equipment

📏 Height Adjustment

📏 Adjustable height front
Yes, standard equipment
📏 Adjustable height rear
Yes, standard equipment

⬆️ Ground Clearance

⬆️ Max ground clearance
121 mm (4.8")
⬇️ Minimum ground clearance
181 mm (7.1")

🔩 Component Types

🔩 Damper type front
ElectronicallyControlled
🔩 Damper type rear
ElectronicallyControlled
🌀 Spring type front
Air
🌀 Spring type rear
Air
⚙️ Suspension type front
DoubleWishbone
⚙️ Suspension type rear
Multilink

Interior

💺 Seating Configuration
This model is available with a seat configuration with five seats.

🪑 Front seats

🏷️ Seat Category

🏷️ Seat type
Driver and Passenger Seat

⚙️ Basic Adjustments

↔️ Seat depth adjustment
Standard electric feature
↕️ Seat height adjustment
Standard electric feature
⤴️ Backrest angle adjustment
Standard electric feature
💾 Memory
Standard driver, not available passenger

🎛️ Advanced Adjustments

📐 Seat cushion angle adjustment
Standard electric driver, not available passenger
🎚️ Height adjustable headrest
Standard feature
📏 Length adjustable headrest
Not Available
🦵 Adjustable thigh support
Not Available
🔄 Backrest side bolster adjustment
Not Available
🔁 Seat cushion side bolster adjustment
Not Available

💆 Comfort Features

🦶 Footrest passenger
Not Available
🔧 Leg support passenger
Not Available
⚡ Electric lumbar adjustment
Standard electric driver, not available passenger
🌬️ Seat ventilation
Standard feature
💆 Massage function
Standard driver, not available passenger

🚗 Second row seats

🏷️ Seat Category

🏷️ Seat type
Three-seat bench

⚙️ Basic Adjustments

↔️ Seat depth adjustment
Not Available
↕️ Seat height adjustment
Not Available
⤴️ Backrest angle adjustment
Standard feature
💾 Memory
Not Available

🎛️ Advanced Adjustments

📐 Seat cushion angle adjustment
Not Available
🎚️ Height adjustable headrest
Standard feature
📏 Length adjustable headrest
Not Available
🦵 Adjustable thigh support
Not Available
🔄 Backrest side bolster adjustment
Not Available
🔁 Seat cushion side bolster adjustment
Not Available

💆 Comfort Features

🦶 Footrest passenger
Not Available
🔧 Leg support passenger
Not Available
⚡ Electric lumbar adjustment
Not Available
🌬️ Seat ventilation
Not Available
💆 Massage function
Not Available

Driver Assistance

Advanced safety and driving assistance features

Lane keeping
Yes, standard equipment
Lane departure warning
Yes, standard equipment
Drowsiness Alert
Yes, standard equipment
Reversing camera
Yes, standard equipment
360 camera
Yes, standard equipment

Sensors & Cameras

Vehicle sensors and camera systems

Ultrasonic sensors
On bumper front
On bumper front
On bumper front left corner
On bumper front right corner
On bumper front left side
On bumper front right side
On bumper rear left side
On bumper rear right side
On bumper rear left corner
On bumper rear right corner
On bumper rear
On bumper rear
Cameras
Top center windshield
Front ((Optional))
On left wing mirror ((Optional))
On right wing mirror ((Optional))
Rear center ((Optional))
Radar sensors
Front
Left rear corner
Right rear corner
Lidar sensors
N/A

UI and controls

User interface and control specifications

Interface Controls

Head-up display
HUD
Not available
Voice control
Voice
Yes, standard equipment
Gesture control
Gesture
Not available
Available screen layouts
Layouts
1

Smartphone Integration

Yes, standard equipment
Yes, standard equipment
Yes, standard equipment

Infotainment

🎵 Audio System

🔊 Number of speakers
20
⚡ Total effect
W

Exterior

🎨 Paint colors

Artic White
Nevis Blue
Black Pearl
Rembrandt Gray
