Kia PV5 Passenger Long Range charging curve & performance

2026, 2027

Last modified: Jun 21, 2026

Below is the charging curve for Kia PV5 Passenger Long Range, illustrating the charging speed at various battery levels. Additionally, graphs for range and time provide comprehensive details on charging performance.

Charging Highlights

Peak DC Speed

150 kW

Battery Capacity

71.2 kWh

Architecture

402 V

71.2 kWh — 71.2 kWh NMC

Estimated Data

The charging curve for this model is derived from manufacturer data and insights into the charging performance of similar battery packs.

Charging curve chart for Kia PV5 Passenger Long Range battery configuration 0

Download charging curve as svg

Charging Performance

Average charging speed 0 - 100% 37.4 kW

Average charging speed 10-100% 34.7 kW

Average charging speed 10-80% 81.7 kW

Advanced Metrics

Max C-Rate 2.11C

Average C-Rate 1.21C

Optimum charging area 0% – 45%

Time Analysis

Download

Range Analysis

Download

Key Insights

Optimum charging speed included 5 minutes loss

87.1 kW

Optimum charge stop time

20m 46s

Charging time 10-80%

34 m 25 s

Charging Speed Analysis

SOC Range	Speed (kW)	Total Time	Energy Added
0-100%	37.4 kW	1 h 47 m 35 s	67.0 kWh
10-100%	34.7 kW	1 h 44 m 18 s	60.3 kWh
10-80%	81.7 kW	34 m 25 s	46.9 kWh

Range Added Per Minute by Driving Cycle

SOC Range	EPA	WLTP	70 mph	120 km/h
0-100%	?	3.8 km (2.4 mi)	?	?
10-100%	?	3.6 km (2.2 mi)	?	?
10-80%	?	8.4 km (5.2 mi)	?	?

Charging Curve Data (0–100% SOC)

SOC	Speed	Time	Energy charged
0%	110 kW	00:00:00	0 kWh
1%	115 kW	00:00:23	0.7 kWh
2%	120 kW	00:00:45	1.3 kWh
3%	125 kW	00:01:06	2.0 kWh
4%	130 kW	00:01:26	2.7 kWh
5%	135 kW	00:01:46	3.4 kWh
6%	138 kW	00:02:05	4.0 kWh
7%	141 kW	00:02:23	4.7 kWh
8%	144 kW	00:02:42	5.4 kWh
9%	147 kW	00:02:59	6.0 kWh
10%	150 kW	00:03:17	6.7 kWh
11%	149 kW	00:03:34	7.4 kWh
12%	148 kW	00:03:52	8.0 kWh
13%	147 kW	00:04:09	8.7 kWh
14%	146 kW	00:04:27	9.4 kWh
15%	145 kW	00:04:45	10.0 kWh
16%	144 kW	00:05:03	10.7 kWh
17%	143 kW	00:05:21	11.4 kWh
18%	142 kW	00:05:39	12.1 kWh
19%	141 kW	00:05:57	12.7 kWh
20%	140 kW	00:06:16	13.4 kWh
21%	138 kW	00:06:34	14.1 kWh
22%	136 kW	00:06:53	14.7 kWh
23%	134 kW	00:07:13	15.4 kWh
24%	132 kW	00:07:32	16.1 kWh
25%	130 kW	00:07:52	16.8 kWh
26%	128 kW	00:08:12	17.4 kWh
27%	126 kW	00:08:32	18.1 kWh
28%	124 kW	00:08:53	18.8 kWh
29%	122 kW	00:09:14	19.4 kWh
30%	120 kW	00:09:36	20.1 kWh
31%	118 kW	00:09:57	20.8 kWh
32%	116 kW	00:10:20	21.4 kWh
33%	114 kW	00:10:42	22.1 kWh
34%	112 kW	00:11:05	22.8 kWh
35%	110 kW	00:11:28	23.4 kWh
36%	108 kW	00:11:52	24.1 kWh
37%	106 kW	00:12:16	24.8 kWh
38%	104 kW	00:12:41	25.5 kWh
39%	102 kW	00:13:06	26.1 kWh
40%	100 kW	00:13:32	26.8 kWh
41%	99 kW	00:13:58	27.5 kWh
42%	98 kW	00:14:25	28.1 kWh
43%	96 kW	00:14:51	28.8 kWh
44%	95 kW	00:15:18	29.5 kWh
45%	94 kW	00:15:46	30.2 kWh
46%	93 kW	00:16:14	30.8 kWh
47%	92 kW	00:16:42	31.5 kWh
48%	90 kW	00:17:10	32.2 kWh
49%	89 kW	00:17:39	32.8 kWh
50%	88 kW	00:18:08	33.5 kWh
51%	87 kW	00:18:38	34.2 kWh
52%	86 kW	00:19:08	34.8 kWh
53%	85 kW	00:19:38	35.5 kWh
54%	84 kW	00:20:09	36.2 kWh
55%	83 kW	00:20:40	36.8 kWh
56%	82 kW	00:21:11	37.5 kWh
57%	81 kW	00:21:43	38.2 kWh
58%	80 kW	00:22:16	38.9 kWh
59%	79 kW	00:22:48	39.5 kWh
60%	78 kW	00:23:21	40.2 kWh
61%	76 kW	00:23:55	40.9 kWh
62%	75 kW	00:24:29	41.5 kWh
63%	73 kW	00:25:04	42.2 kWh
64%	72 kW	00:25:40	42.9 kWh
65%	70 kW	00:26:17	43.6 kWh
66%	68 kW	00:26:54	44.2 kWh
67%	67 kW	00:27:32	44.9 kWh
68%	65 kW	00:28:12	45.6 kWh
69%	64 kW	00:28:52	46.2 kWh
70%	62 kW	00:29:33	46.9 kWh
71%	60 kW	00:30:16	47.6 kWh
72%	59 kW	00:30:59	48.2 kWh
73%	57 kW	00:31:44	48.9 kWh
74%	55 kW	00:32:31	49.6 kWh
75%	54 kW	00:33:18	50.2 kWh
76%	52 kW	00:34:07	50.9 kWh
77%	50 kW	00:34:58	51.6 kWh
78%	48 kW	00:35:51	52.3 kWh
79%	47 kW	00:36:46	52.9 kWh
80%	45 kW	00:37:42	53.6 kWh
81%	43 kW	00:38:41	54.3 kWh
82%	41 kW	00:39:43	54.9 kWh
83%	39 kW	00:40:48	55.6 kWh
84%	37 kW	00:41:56	56.3 kWh
85%	35 kW	00:43:08	57.0 kWh
86%	33 kW	00:44:24	57.6 kWh
87%	31 kW	00:45:45	58.3 kWh
88%	29 kW	00:47:12	59.0 kWh
89%	27 kW	00:48:44	59.6 kWh
90%	25 kW	00:50:24	60.3 kWh
91%	22 kW	00:52:14	61.0 kWh
92%	20 kW	00:54:17	61.6 kWh
93%	17 kW	00:56:39	62.3 kWh
94%	14 kW	00:59:24	63.0 kWh
95%	12 kW	01:02:44	63.6 kWh
96%	9 kW	01:06:55	64.3 kWh
97%	6 kW	01:12:33	65.0 kWh
98%	4 kW	01:21:12	65.7 kWh
99%	1 kW	01:39:43	66.3 kWh
100%	10 kW	01:47:35	67.0 kWh
