Ford Mustang Mach-E Long Range AWD specifications

MY2021, MY2022, MY2023
Last modified: Jan 31, 2026

EVKX.net provides full specifications for Ford Mustang Mach-E Long Range AWD.

EVKX.net seeks to have the most complete specifications for Ford Mustang Mach-E Long Range AWD. Click on image above for full article, visit the image gallery for high-res images of Ford Mustang Mach-E Long Range AWD, visit the chargeinfo for Ford Mustang Mach-E Long Range AWD with chargecurve, visit extended range info for real world ranges.
Ford Mustang Mach-E Long Range AWD

Ford Mustang Mach-E Long Range AWD

Performance

Power, torque and acceleration specifications

Power & Torque

Peak power
Power
258 KW (351 hp /346 bhp)
Electrical torque output
Torque
580 nm (428 lb-ft)

Speed & Acceleration

Top speed
Top Speed
180 kph (112 mph)
0-100km/h (0-62 mph)
0-100 km/h
5.1 s

Range & Consumption

Official test cycle results and real-world estimates

Below you see the offical range info. Visit our extended range info for detailed real world range examples. Visit our Range Guide to see what affects range and how the offical range values are measured.
Basic trim WLTP range
540 km
WLTP
Basic trim WLTP consumption
1496.3 kWh/100km
Real-world
Basic trim WLTP consumption with charging loss
18.7 kWh/100km
WLTP
Top trim WLTP range
545 km
WLTP
Top trim WLTP consumption
1482.6 kWh/100km
Real-world
Top trim WLTP consumption with charging loss
18 kWh/100km
WLTP
x.models.Models

Battery & Charging

Battery specifications and charging capabilities

Battery gross
98.7 kWh
Gross
Battery net
8080 kWh
Usable
Max DC charging
150 kW
Peak DC
Number of modules
Pack Configuration
94s4p
Nominal voltage
V
Cathode Materials
NMC

Chargeport

Charging port specifications by region

Spec
LeftFrontSide
Type chargeport Europe
CCS2
Europe
Type chargeport North America
CCS1
North America
Type chargeport Oceania (Australia, New Zealand ++)
CCS2
Oceania

Dimensions

📏 Basic Dimensions

📏 Length
4713 mm (185.6")
📐 Height
1625 mm (64.0")
↔️ Width excluding mirrors
1881 mm (74.1")
🔄 Width including mirrors
2097 mm (82.6")

🛞 Wheelbase & Track

🛞 Wheelbase
2984 mm (117.5")
⚪ Track width front
1617 mm (63.7")
⚫ Track width rear
1626 mm (64.0")

💨 Aerodynamics

💨 Drag coefficient
📐 Frontal area
m²

⛰️ Clearance & Turning

⛰️ Approach Angle
🏔️ Departure Angle
🔄 Turning circle
11.6 meter (456.7")

Cargo Capacity and Towing Ability

Weight, cargo capacity and towing specifications

Weight Specifications

Curb weight
Empty Weight
2182 kg (4810 lbs)
2690 kg (5930 lbs)
508 kg (1120 lbs)
0 kg (0 lbs)

Cargo Capacity

402 liter (14 cu-ft)
1420 liter (50 cu-ft)
100 liter (4 cu-ft)

Towing Capacity

750 kg (1653 lbs)
750 kg (1653 lbs)
Maximum tow ball weight
Tongue
30 kg (66 lbs)

Suspension

🎛️ Adaptive Features

🎛️ Adaptive suspension
Not available
🔧 Adjustable damping front
Not available
🔧 Adjustable damping rear
Not available

📏 Height Adjustment

📏 Adjustable height front
Not available
📏 Adjustable height rear
Not available

⬆️ Ground Clearance

⬆️ Max ground clearance
147 mm (5.8")
⬇️ Minimum ground clearance
147 mm (5.8")

🔩 Component Types

🔩 Damper type front
Monotube
🔩 Damper type rear
Monotube
🌀 Spring type front
Coil
🌀 Spring type rear
Coil
⚙️ Suspension type front
MacPhersonStrut
⚙️ Suspension type rear
Multilink

Interior

💺 Seating Configuration
This model is available with a seat configuration with five seats.

🪑 Front seats

🏷️ Seat Category

🏷️ Seat type
Driver and Passenger Seat

⚙️ Basic Adjustments

↔️ Seat depth adjustment
Standard electric feature
↕️ Seat height adjustment
Standard electric feature
⤴️ Backrest angle adjustment
Standard electric feature
💾 Memory
Standard driver, not available passenger

🎛️ Advanced Adjustments

📐 Seat cushion angle adjustment
Not Available
🎚️ Height adjustable headrest
Standard feature
📏 Length adjustable headrest
Not Available
🦵 Adjustable thigh support
Not Available
🔄 Backrest side bolster adjustment
Not Available
🔁 Seat cushion side bolster adjustment
Not Available

💆 Comfort Features

🦶 Footrest passenger
Not Available
🔧 Leg support passenger
Not Available
⚡ Electric lumbar adjustment
Standard electric feature
🌬️ Seat ventilation
Not Available
💆 Massage function
Not Available

🚗 Second row seats

🏷️ Seat Category

🏷️ Seat type
Three-seat bench

⚙️ Basic Adjustments

↔️ Seat depth adjustment
Not Available
↕️ Seat height adjustment
Not Available
⤴️ Backrest angle adjustment
Not Available
💾 Memory
Not Available

🎛️ Advanced Adjustments

📐 Seat cushion angle adjustment
Not Available
🎚️ Height adjustable headrest
Standard feature
📏 Length adjustable headrest
Not Available
🦵 Adjustable thigh support
Not Available
🔄 Backrest side bolster adjustment
Not Available
🔁 Seat cushion side bolster adjustment
Not Available

💆 Comfort Features

🦶 Footrest passenger
Not Available
🔧 Leg support passenger
Not Available
⚡ Electric lumbar adjustment
Not Available
🌬️ Seat ventilation
Not Available
💆 Massage function
Not Available

Driver Assistance

Advanced safety and driving assistance features

Lane keeping
Yes, standard equipment
Lane departure warning
Yes, standard equipment
Drowsiness Alert
Yes, standard equipment
Reversing camera
Yes, standard equipment
360 camera
Yes, standard equipment

Sensors & Cameras

Vehicle sensors and camera systems

Ultrasonic sensors
On bumper rear left side
On bumper rear right side
On bumper rear left corner
On bumper rear right corner
On bumper rear
On bumper rear
On bumper front left side
On bumper front right side
On bumper front left corner
On bumper front right corner
On bumper front
On bumper front
Cameras
Top center windshield
Front
On left wing mirror
On right wing mirror
Rear center
Radar sensors
Front
Lidar sensors
N/A

UI and controls

User interface and control specifications

Interface Controls

Head-up display
HUD
Not available
Voice control
Voice
Yes, optional equipment
Gesture control
Gesture
Not available
Available screen layouts
Layouts
1

Smartphone Integration

Yes, standard equipment
Yes, standard equipment
Yes, standard equipment

Infotainment

🎵 Audio System

🔊 Number of speakers
10
⚡ Total effect
540 W

Exterior

🎨 Paint colors

Absolute Black
Vapor Blue
Grabber Blue
Space White
Star White
Rapid Red
Carbonized Gray
Cyber Orange
