Audi Q4 40 e-tron laddningskurva och prestanda
Nedan är laddningskurvan för Audi Q4 40 e-tron, som visar laddningshastigheten vid olika batterinivåer. Dessutom ger grafer för räckvidd och tid omfattande detaljer om laddningsprestanda.
63,0 kWh — 63 kWh
| Specifikation | Värde |
|---|---|
| Genomsnittlig laddningshastighet 0-100% | 76,5 kW |
| Genomsnittlig laddningshastighet 10-100% | 72,9 kW |
| Genomsnittlig laddningshastighet 10-90% | 85,8 kW |
| Genomsnittlig laddningshastighet 10-80% | 95,1 kW |
| Max C-värde | 2,68 |
| Genomsnittlig C-värde | 1,64 |
| Optimalt laddningsområde | 1% – 45% |
| Optimal laddningshastighet inklusive 5 minuters förlust | 93,6 kW |
| Optimal laddningstid | 16m 38s |
| Specifikation | Värde |
|---|---|
| Laddningstid 0-100% | 46 m 16 s |
| Laddningstid 10-100% | 43 m 41 s |
| Laddningstid 10-80% | 26 m 3 s |
| EPA cycle | WLTP cycle | 70 mph | 120 km/h | |
|---|---|---|---|---|
| Räckvidd per minut 0-100% | ? | 8,9 km (5,5 mi) | 6,1 km (3,8 mi) | 5,8 km (3,6 mi) |
| Räckvidd per minut 10-100% | ? | 8,5 km (5,3 mi) | 5,8 km (3,6 mi) | 5,5 km (3,4 mi) |
| Räckvidd per minut 10-80% | ? | 11,1 km (6,9 mi) | 7,5 km (4,7 mi) | 7,2 km (4,5 mi) |
Laddningsdata
| Laddningsnivå | Hastighet | Tid | Laddad energi |
|---|---|---|---|
| 0 % | 60 kW | 00:00:00 | 0 kWh |
| 1 % | 112 kW | 00:00:26 | 0,6 kWh |
| 2 % | 160 kW | 00:00:43 | 1,2 kWh |
| 3 % | 161 kW | 00:00:57 | 1,8 kWh |
| 4 % | 162 kW | 00:01:11 | 2,4 kWh |
| 5 % | 164 kW | 00:01:25 | 3,0 kWh |
| 6 % | 165 kW | 00:01:39 | 3,5 kWh |
| 7 % | 166 kW | 00:01:53 | 4,1 kWh |
| 8 % | 167 kW | 00:02:07 | 4,7 kWh |
| 9 % | 168 kW | 00:02:20 | 5,3 kWh |
| 10 % | 169 kW | 00:02:34 | 5,9 kWh |
| 11 % | 169 kW | 00:02:47 | 6,5 kWh |
| 12 % | 169 kW | 00:03:01 | 7,1 kWh |
| 13 % | 169 kW | 00:03:14 | 7,7 kWh |
| 14 % | 169 kW | 00:03:28 | 8,3 kWh |
| 15 % | 169 kW | 00:03:41 | 8,8 kWh |
| 16 % | 166 kW | 00:03:55 | 9,4 kWh |
| 17 % | 167 kW | 00:04:09 | 10,0 kWh |
| 18 % | 167 kW | 00:04:22 | 10,6 kWh |
| 19 % | 167 kW | 00:04:36 | 11,2 kWh |
| 20 % | 166 kW | 00:04:50 | 11,8 kWh |
| 21 % | 167 kW | 00:05:03 | 12,4 kWh |
| 22 % | 167 kW | 00:05:17 | 13,0 kWh |
| 23 % | 167 kW | 00:05:31 | 13,6 kWh |
| 24 % | 168 kW | 00:05:44 | 14,2 kWh |
| 25 % | 163 kW | 00:05:58 | 14,8 kWh |
| 26 % | 162 kW | 00:06:12 | 15,3 kWh |
| 27 % | 158 kW | 00:06:27 | 15,9 kWh |
| 28 % | 155 kW | 00:06:41 | 16,5 kWh |
| 29 % | 153 kW | 00:06:56 | 17,1 kWh |
| 30 % | 149 kW | 00:07:11 | 17,7 kWh |
| 31 % | 147 kW | 00:07:27 | 18,3 kWh |
| 32 % | 144 kW | 00:07:42 | 18,9 kWh |
| 33 % | 141 kW | 00:07:58 | 19,5 kWh |
| 34 % | 138 kW | 00:08:15 | 20,1 kWh |
| 35 % | 129 kW | 00:08:32 | 20,6 kWh |
| 36 % | 116 kW | 00:08:50 | 21,2 kWh |
| 37 % | 111 kW | 00:09:11 | 21,8 kWh |
| 38 % | 108 kW | 00:09:31 | 22,4 kWh |
| 39 % | 107 kW | 00:09:53 | 23,0 kWh |
| 40 % | 107 kW | 00:10:14 | 23,6 kWh |
| 41 % | 105 kW | 00:10:36 | 24,2 kWh |
| 42 % | 105 kW | 00:10:57 | 24,8 kWh |
| 43 % | 103 kW | 00:11:19 | 25,4 kWh |
| 44 % | 102 kW | 00:11:42 | 26,0 kWh |
| 45 % | 100 kW | 00:12:04 | 26,6 kWh |
| 46 % | 100 kW | 00:12:27 | 27,1 kWh |
| 47 % | 102 kW | 00:12:50 | 27,7 kWh |
| 48 % | 100 kW | 00:13:12 | 28,3 kWh |
| 49 % | 96 kW | 00:13:36 | 28,9 kWh |
| 50 % | 93 kW | 00:14:00 | 29,5 kWh |
| 51 % | 95 kW | 00:14:24 | 30,1 kWh |
| 52 % | 94 kW | 00:14:48 | 30,7 kWh |
| 53 % | 92 kW | 00:15:13 | 31,3 kWh |
| 54 % | 91 kW | 00:15:38 | 31,9 kWh |
| 55 % | 90 kW | 00:16:03 | 32,4 kWh |
| 56 % | 88 kW | 00:16:29 | 33,0 kWh |
| 57 % | 87 kW | 00:16:55 | 33,6 kWh |
| 58 % | 87 kW | 00:17:21 | 34,2 kWh |
| 59 % | 86 kW | 00:17:47 | 34,8 kWh |
| 60 % | 85 kW | 00:18:14 | 35,4 kWh |
| 61 % | 85 kW | 00:18:41 | 36,0 kWh |
| 62 % | 83 kW | 00:19:08 | 36,6 kWh |
| 63 % | 82 kW | 00:19:36 | 37,2 kWh |
| 64 % | 82 kW | 00:20:04 | 37,8 kWh |
| 65 % | 81 kW | 00:20:32 | 38,4 kWh |
| 66 % | 80 kW | 00:21:00 | 38,9 kWh |
| 67 % | 78 kW | 00:21:29 | 39,5 kWh |
| 68 % | 77 kW | 00:21:58 | 40,1 kWh |
| 69 % | 75 kW | 00:22:28 | 40,7 kWh |
| 70 % | 74 kW | 00:22:59 | 41,3 kWh |
| 71 % | 73 kW | 00:23:30 | 41,9 kWh |
| 72 % | 71 kW | 00:24:02 | 42,5 kWh |
| 73 % | 70 kW | 00:24:34 | 43,1 kWh |
| 74 % | 69 kW | 00:25:07 | 43,7 kWh |
| 75 % | 68 kW | 00:25:40 | 44,2 kWh |
| 76 % | 67 kW | 00:26:14 | 44,8 kWh |
| 77 % | 65 kW | 00:26:49 | 45,4 kWh |
| 78 % | 64 kW | 00:27:24 | 46,0 kWh |
| 79 % | 62 kW | 00:28:01 | 46,6 kWh |
| 80 % | 61 kW | 00:28:38 | 47,2 kWh |
| 81 % | 60 kW | 00:29:15 | 47,8 kWh |
| 82 % | 59 kW | 00:29:54 | 48,4 kWh |
| 83 % | 58 kW | 00:30:33 | 49,0 kWh |
| 84 % | 56 kW | 00:31:13 | 49,6 kWh |
| 85 % | 55 kW | 00:31:54 | 50,2 kWh |
| 86 % | 54 kW | 00:32:36 | 50,7 kWh |
| 87 % | 53 kW | 00:33:19 | 51,3 kWh |
| 88 % | 52 kW | 00:34:02 | 51,9 kWh |
| 89 % | 50 kW | 00:34:47 | 52,5 kWh |
| 90 % | 49 kW | 00:35:33 | 53,1 kWh |
| 91 % | 48 kW | 00:36:20 | 53,7 kWh |
| 92 % | 47 kW | 00:37:08 | 54,3 kWh |
| 93 % | 45 kW | 00:37:58 | 54,9 kWh |
| 94 % | 41 kW | 00:38:51 | 55,5 kWh |
| 95 % | 38 kW | 00:39:49 | 56,0 kWh |
| 96 % | 35 kW | 00:40:51 | 56,6 kWh |
| 97 % | 31 kW | 00:42:01 | 57,2 kWh |
| 98 % | 28 kW | 00:43:18 | 57,8 kWh |
| 99 % | 25 kW | 00:44:44 | 58,4 kWh |
| 100 % | 25 kW | 00:46:16 | 59,0 kWh |
